产品介绍
CR24 50
3V
开关按键 重置按钮
LED指示灯
产品参数
产品型号: SNZB-01
电池型号: CR2450
工作电压: 3V
无线连接: ZigBee (IEEE 802.15.4)
工作温度: -10-40℃
工作湿度:10-90%RH(无冷凝)
外壳材料: PC
产品规格: 43x43x16mm
5

Other manuals for Sonoff SNZB-01

Preview: User Manual
User Manual6 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sonoff SNZB-01 and is the answer not in the manual?

Sonoff SNZB-01 Specifications

General IconGeneral
ModelSNZB-01
TypeWireless Switch
Wireless ProtocolZigbee
BatteryCR2032
Operating Temperature-10°C to 40°C
Dimensions43mm x 43mm x 16mm
