Sonora A - Installation

INSTALLATION
4
CHECKING THE ATTACHED ITEMS:
please contact us.
INSTALLING THE PIANO LEGS:
with the allen key.
on the picture below.
Precautions for installing solid wood piano legs
1、The sticker is facing upwards.
2、Align the screw holes and pay attention to distinguishing the orientation of the wooden legs.
After installation and fastening, the two wooden legs should be in an outward eight shape.
(Figure 1, Figure 2)
3、When tightening screws, first tighten the first screw halfway to facilitate adjustment of other screw holes.
4、If you feel that there is obstruction when installing screws, please loosen the screws back before tightening
them.
5、Each set of piano legs comes with an additional 2 spare screws.
Figure 1 Figure 2
Please distinguish between
the front and back sides
(with the sticker facing upwards)
sticker
6
Power
5
A
c
B
Piano-body
Wooden-legs (Left/right Sides)
Screws（6 Pcs）
A
B
C
Volume:
Turn the volume knob to
adjust the volume.
Power:
To turn on the piano, press
the power button. To switch
off the piano, press and
hold the power button for
Open outwards
