SonTek
ADP Software Manual Version 6.42 (November 1, 2000)
10
Temp (°C)
Displays the most-recent data from the ADP temperature sensor.
Pressure (dB)
Displays the most-recent data from the optional ADP pressure sensor, in dBar. This field will
show 0 if the pressure sensor is not installed.
Bottom Track Display (if enabled)
Displays the most-recent bottom-track data: averaged depth (m), Veast and Vnorth (cm/s).
GPS Navigation Display (if present)
Displays the most-recent position (Lat & Long) and vessel spees (Veast and Vnorth (cm/s)).
Waves Display (if enabled)
Displays the most-recent wave data: Significant wave height (H
mo
, cm) and wave peak period
(T
p
, s).
External CTD Display (if present)
Displays the most-recent data acquired from an external CTD: temperature (°C), conductivity
{Siemens), pressure {dbar) and salinity, (ppt).).
Figure 2 – ADPSA Real-Time Data Acquisition Display
