Sony CA-570P - Location and Function of Parts and Controls; CA-570 P Controls and Connectors; CA-570 Controls and Connectors

Location and Function of Parts and Controls
4(E)
Location and Function of Parts and Controls
3 PGM level controls and PROD/
ENG switches
4 INCOM level controls, PROD/ENG
switches, and LEVEL/MIC switches
5 Triax connector
6 INCOM 1/2 connector
7 VTR connector
8 REMOTE connectors
9 DC IN connector
!º PROMPTER/GEN LOCK connector
!™ TEST OUT connector
!£ RET CONT connector
!¢ TRACKER connector
!∞ EARPHONE jack
!ª PGM level control
@º ENG level control
@¡ MIC LINE
switch
@™ PROD level control
@£ TRACKER level control
@¢ LEVEL/MIC switch
CA-570
CA-570P
1 RET1 button/RET button and RET 2/3/4 switch
2 TALLY lamp and TALLY switch
!¡ AUDIO IN 1/AUDIO IN 2 connectors and LINE/MIC switch
and external power supply mode switch for the microphone
!• DC OUT connector
!¶ POWER switch and indicator
!§ CALL button
