Sony CBK-CE01 - Installation Procedure

1-3 (E)
CBK-CE01
1-2. Installation Procedure
1. Remove the four screws to detach the 50P cover assembly.
50P cover assembly
M2
2. Loosen the four screws with stopper to detach the inside panel assembly.
Screws with stopper
Screws with stopper
Inside panel assembly
3. Install the 50P CN assembly with the supplied four screws (B2 x 5).
50P CN assembly
B2 x 5
