Sony CCD-TR315 - Page 71

CCD-TR315/TR416/TR416PK/TR516/TR516PK/TR716
CCD-TRV16/TRV16PK/TRV36/TRV36PK/TRV43/TRV46/TRV46PK
4-75 4-76
4-77
4-78
CONTROL
CF-61 (TRV Series)
CF-61 (CONTROL (TRV Series) PRINTED WIRING BOARD
– Ref No. CF-61 BOARD: 9,000 series –
• For Printed Wiring Boards.
• Chip transistor Chip diode
There are few cases that the part isn't mounted in this model is
printed on this diagram.
C
Q
BE
CF-61 BOARD
BH001 B-9
C001 B-6
C002 A-6
CN001 C-4
CN002 A-5
CN005 C-7
CN006 B-7
CN007 C-5
CN009 B-6
CN010 A-3
D004 A-13
D005 B-7
D006 A-7
D007 A-14
D008 A-6
D009 B-1
D010 C-3
D012 A-4
Q002 C-1
R001 B-1
R002 B-6
R005 A-13
R007 C-1
R013 A-13
R022 B-13
R023 B-14
R029 C-2
R031 B-4
R032 C-11
R036 C-2
R038 B-4
R039 C-2
R041 A-4
R051 C-5
R052 C-5
R053 A-4
R054 A-12
S006 A-13
S010 B-14
S015 A-15
S022 C-11
3
21
CCD-TR315/TR416/TR416PK/TR516/TR516PK/TR716
CCD-TRV16/TRV16PK/TRV36/TRV36PK/TRV43/TRV46/TRV46PK
EXPOSUE
MENU
SELECT-DIAL
DATE
TIME
5SEC PUSH NOR
REC MODE
COUNTER
RESET
TITLEDISPLAY
END
SEARCH
EFECT
BACK
LIGHT
PROGRAM
AE
(LITHIUM BATTERY HOLDER)
CF-61 BOARD (SIDE B) CF-61 BOARD (SIDE A)
12345678910
A
B
C
D
E
09
11 12 13 14 15
1-672-469-
11 21
VF-99... B/W EVF models only
(B/W EVF)
PD-107... TRV series only
RGB decoder, LCD,
LCD drive, Back light
CF-61...
TRV series only
(Control)
SE-80...
TR716 only
SE-81... TRV series only
(Steady shot)
CD-210...
TR series only
CD-211... TRV series only
(CCD imager)
