Sony CDX-C4750 - Page 44

– 56 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
D909 8-719-977-12 DIODE DTZ6.8B
D910 8-719-017-91 DIODE MA8160
D912 8-719-923-60 DIODE MTZJ-T-77-9.1A
D913 8-719-109-89 DIODE RD5.6ESB2
D914 8-719-977-12 DIODE DTZ6.8B
D915 8-719-923-60 DIODE MTZJ-T-77-9.1A
D916 8-719-921-80 DIODE MTZJ-11B
D918 8-719-914-44 DIODE DAP202K
D919 8-719-914-43 DIODE DAN202K
D920 8-719-977-12 DIODE DTZ6.8B
D924 8-719-200-82 DIODE 11ES2
< IC >
IC200 8-759-490-74 IC TDA7384
IC401 8-759-572-10 IC TDA7462D013TR
IC601 8-759-572-11 IC TDA7427AD1TR
IC702 8-759-464-81 IC PCM1717E-ST2
IC801 8-759-572-13 IC MB90574PFV-G-193-BND
IC803 8-759-449-89 IC BA8270F-E2
IC901 8-759-572-12 IC BA4903
IC902 8-759-363-81 IC XC61AN4002PR
< JUMPER RESISTOR >
JR124 1-216-295-00 SHORT 0
JR125 1-216-295-00 SHORT 0
JR224 1-216-295-00 SHORT 0
JR225 1-216-295-00 SHORT 0
JR601 1-216-295-00 SHORT 0
JR611 1-216-295-00 SHORT 0
JR613 1-216-295-00 SHORT 0
JR616 1-216-295-00 SHORT 0
JR617 1-216-295-00 SHORT 0
JR618 1-216-295-00 SHORT 0
JR620 1-216-295-00 SHORT 0
JR621 1-216-295-00 SHORT 0
JR622 1-216-295-00 SHORT 0
JR624 1-216-295-00 SHORT 0
JR702 1-216-295-00 SHORT 0
JR705 1-216-295-00 SHORT 0
JR710 1-216-295-00 SHORT 0
JR720 1-216-295-00 SHORT 0
JR722 1-216-295-00 SHORT 0
JR765 1-216-295-00 SHORT 0
JR855 1-216-295-00 SHORT 0 (C4750)
JR856 1-216-295-00 SHORT 0 (C6600)
JR857 1-216-295-00 SHORT 0
< COIL >
JW601 1-414-137-31 INDUCTOR 0.22uH
L601 1-410-513-11 INDUCTOR 22uH
L802 1-216-295-00 SHORT 0
L901 1-416-539-11 INDUCTOR 370uH
< JACK >
PJ400 1-774-700-11 JACK, PIN 6P (BUS AUDIO IN,
LINE OUT FRONT/REAR)
< TRANSISTOR >
Q110 8-729-920-31 TRANSISTOR DTC343TK
Q111 8-729-920-31 TRANSISTOR DTC343TK
Q210 8-729-920-31 TRANSISTOR DTC343TK
Q211 8-729-920-31 TRANSISTOR DTC343TK
Q401 8-729-901-05 TRANSISTOR DTA124EK
Q402 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q603 8-729-030-51 TRANSISTOR 2SA1515S-R-TP
Q609 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q610 8-729-216-22 TRANSISTOR 2SA1162-G
Q612 8-729-216-22 TRANSISTOR 2SA1162-G
Q613 8-729-620-06 TRANSISTOR 2SC3052-EF
Q614 8-729-620-06 TRANSISTOR 2SC3052-EF
Q615 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q901 8-729-901-05 TRANSISTOR DTA124EK
Q902 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q903 8-729-019-00 TRANSISTOR 2SD2394-G
Q904 8-729-019-00 TRANSISTOR 2SD2394-G
Q905 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q906 8-729-620-06 TRANSISTOR 2SC3052-EF
Q907 8-729-901-05 TRANSISTOR DTA124EK
Q908 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q909 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q910 8-729-901-05 TRANSISTOR DTA124EK
Q911 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q912 8-729-019-00 TRANSISTOR 2SD2394-G
Q913 8-729-901-05 TRANSISTOR DTA124EK
Q914 8-729-901-05 TRANSISTOR DTA124EK
Q915 8-729-901-05 TRANSISTOR DTA124EK
Q916 8-729-620-06 TRANSISTOR 2SC3052-EF
Q919 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q924 8-729-101-07 TRANSISTOR 2SB798-DL
Q925 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R101 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R112 1-216-049-11 RES,CHIP 1K 5% 1/10W
R113 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R114 1-216-049-11 RES,CHIP 1K 5% 1/10W
R115 1-216-075-00 METAL CHIP 12K 5% 1/10W
R116 1-216-075-00 METAL CHIP 12K 5% 1/10W
R117 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R118 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R123 1-216-081-00 METAL CHIP 22K 5% 1/10W
(C4750)
