– 57 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R123 1-216-089-00 RES,CHIP 47K 5% 1/10W
(C6600)
R127 1-216-064-00 METAL CHIP 4.3K 5% 1/10W
R128 1-216-082-00 RES,CHIP 24K 5% 1/10W
R129 1-216-082-00 RES,CHIP 24K 5% 1/10W
R130 1-216-089-00 RES,CHIP 47K 5% 1/10W
R201 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R202 1-216-073-00 METAL CHIP 10K 5% 1/10W
R211 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R212 1-216-049-11 RES,CHIP 1K 5% 1/10W
R213 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R214 1-216-049-11 RES,CHIP 1K 5% 1/10W
R215 1-216-075-00 METAL CHIP 12K 5% 1/10W
R216 1-216-075-00 METAL CHIP 12K 5% 1/10W
R217 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R218 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R223 1-216-081-00 METAL CHIP 22K 5% 1/10W
(C4750)
R223 1-216-089-00 RES,CHIP 47K 5% 1/10W
(C6600)
R227 1-216-064-00 METAL CHIP 4.3K 5% 1/10W
R228 1-216-082-00 RES,CHIP 24K 5% 1/10W
R229 1-216-082-00 RES,CHIP 24K 5% 1/10W
R230 1-216-089-00 RES,CHIP 47K 5% 1/10W
R401 1-216-049-11 RES,CHIP 1K 5% 1/10W
R402 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R403 1-216-113-00 METAL CHIP 470K 5% 1/10W
R404 1-216-295-00 SHORT 0
R405 1-216-295-00 SHORT 0
R408 1-216-077-00 METAL CHIP 15K 5% 1/10W
R601 1-216-097-00 RES,CHIP 100K 5% 1/10W
R602 1-216-025-00 RES,CHIP 100 5% 1/10W
R603 1-216-083-00 METAL CHIP 27K 5% 1/10W
R605 1-216-082-00 RES,CHIP 24K 5% 1/10W
R606 1-216-073-00 METAL CHIP 10K 5% 1/10W
R607 1-216-097-00 RES,CHIP 100K 5% 1/10W
R608 1-216-025-00 RES,CHIP 100 5% 1/10W
R609 1-216-089-00 RES,CHIP 47K 5% 1/10W
R611 1-216-025-00 RES,CHIP 100 5% 1/10W
R613 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R614 1-216-295-00 SHORT 0
R615 1-216-295-00 SHORT 0
R617 1-216-041-00 METAL CHIP 470 5% 1/10W
R619 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R628 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R629 1-216-097-00 RES,CHIP 100K 5% 1/10W
R630 1-216-097-00 RES,CHIP 100K 5% 1/10W
R631 1-216-097-00 RES,CHIP 100K 5% 1/10W
R632 1-216-049-11 RES,CHIP 1K 5% 1/10W
R637 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R638 1-216-097-00 RES,CHIP 100K 5% 1/10W
R639 1-216-077-00 METAL CHIP 15K 5% 1/10W
R640 1-216-113-00 METAL CHIP 470K 5% 1/10W
R692 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R694 1-216-017-00 RES,CHIP 47 5% 1/10W
R695 1-216-097-00 RES,CHIP 100K 5% 1/10W
R696 1-216-064-00 METAL CHIP 4.3K 5% 1/10W
(C4750)
R696 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
(C6600)
R697 1-216-064-00 METAL CHIP 4.3K 5% 1/10W
(C4750)
R697 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
(C6600)
R698 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R699 1-216-079-00 METAL CHIP 18K 5% 1/10W
R701 1-216-025-00 RES,CHIP 100 5% 1/10W
R702 1-216-025-00 RES,CHIP 100 5% 1/10W
R703 1-216-025-00 RES,CHIP 100 5% 1/10W
R705 1-216-033-00 METAL CHIP 220 5% 1/10W
R706 1-216-049-11 RES,CHIP 1K 5% 1/10W
R708 1-216-037-00 METAL CHIP 330 5% 1/10W
R710 1-216-027-00 METAL CHIP 120 5% 1/10W
R723 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R802 1-216-049-11 RES,CHIP 1K 5% 1/10W
R806 1-216-049-11 RES,CHIP 1K 5% 1/10W
R807 1-216-049-11 RES,CHIP 1K 5% 1/10W
R808 1-216-049-11 RES,CHIP 1K 5% 1/10W
R809 1-216-025-00 RES,CHIP 100 5% 1/10W
R810 1-216-025-00 RES,CHIP 100 5% 1/10W
R813 1-216-049-11 RES,CHIP 1K 5% 1/10W
R814 1-216-049-11 RES,CHIP 1K 5% 1/10W
R822 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R823 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R825 1-216-097-00 RES,CHIP 100K 5% 1/10W
R826 1-216-097-00 RES,CHIP 100K 5% 1/10W
R827 1-216-105-00 RES,CHIP 220K 5% 1/10W
R828 1-216-097-00 RES,CHIP 100K 5% 1/10W
R829 1-216-073-00 METAL CHIP 10K 5% 1/10W
R830 1-216-073-00 METAL CHIP 10K 5% 1/10W
R831 1-216-073-00 METAL CHIP 10K 5% 1/10W
R832 1-216-097-00 RES,CHIP 100K 5% 1/10W
R833 1-216-049-11 RES,CHIP 1K 5% 1/10W
R834 1-216-097-00 RES,CHIP 100K 5% 1/10W
R839 1-216-073-00 METAL CHIP 10K 5% 1/10W
R840 1-216-089-00 RES,CHIP 47K 5% 1/10W
R841 1-216-025-00 RES,CHIP 100 5% 1/10W
R842 1-216-097-00 RES,CHIP 100K 5% 1/10W
R843 1-216-073-00 METAL CHIP 10K 5% 1/10W
R844 1-216-025-00 RES,CHIP 100 5% 1/10W
R845 1-216-025-00 RES,CHIP 100 5% 1/10W
R846 1-216-097-00 RES,CHIP 100K 5% 1/10W
R847 1-216-097-00 RES,CHIP 100K 5% 1/10W
R848 1-216-097-00 RES,CHIP 100K 5% 1/10W
R850 1-216-097-00 RES,CHIP 100K 5% 1/10W
(C6600)
