CHANGE OF ELECTRICAL PARTS LIST
(Service Manual See page 39 to 43)
C303 –––––––––––
C316 1-136-165-00 FILM 0.1uF 5% 50V
C334 –––––––––––
C716 1-136-169-00 FILM 0.22uF 5% 50V
C735 1-162-294-31 CERAMIC 0.001uF 10% 50V
C739 1-162-207-31 CERAMIC 22PF 5% 50V
(US,CND,C&SA)
C748 1-162-306-11 CERAMIC 0.01uF 20% 16V
C750 1-136-153-00 FILM 0.01uF 5% 50V
C755 1-162-306-11 CERAMIC 0.01uF 20% 16V
C756 1-162-306-11 CERAMIC 0.01uF 20% 16V
C759 1-162-306-11 CERAMIC 0.01uF 20% 16V
C765 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,IT,E,SP)
C788 1-162-306-11 CERAMIC 0.01uF 20% 16V
C821 1-162-306-11 CERAMIC 0.01uF 20% 16V
D301 8-719-010-55 DIODE UZ-7.5BSC
D310 –––––––––––
D804 8-719-987-63 DIODE 1N4148M
D815 –––––––––––
Q952 8-729-037-11 TRANSISTOR KTA1271Y-AT
R728 1-249-417-11 CARBON 1K 5% 1/4W
(US,CND,C&SA)
R760 1-249-417-11 CARBON 1K 5% 1/4W
(AEP,IT,E,SP)
R822 –––––––––––
R890 –––––––––––
R937 –––––––––––
R954 –––––––––––
R955 –––––––––––
R956 –––––––––––
R957 –––––––––––
S821 1-762-758-11 SWITCH, KEYBOARD (RESET)
1-162-306-11 CERAMIC 0.01uF 20% 16V
1-136-153-00 FILM 0.01uF 5% 50V
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-136-153-00 FILM 0.01uF 5% 50V
1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,IT,E,SP)
–––––––––––
1-161-494-00 CERAMIC 0.022uF 25V
(AEP,IT,E,SP)
1-136-153-00 FILM 0.01uF 5% 50V
(AEP,IT,E,SP)
1-161-494-00 CERAMIC 0.022uF 5% 25V
(US,CND,C&SA)
1-162-294-31 CERAMIC 0.001uF 10% 50V
(US,CND,C&SA)
1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,IT,E,SP)
1-162-294-31 CERAMIC 0.001uF 10% 50V
(US,CND,C&SA)
1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,IT,E,SP)
1-162-294-31 CERAMIC 0.001uF 10% 50V
(US,CND,C&SA)
1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,IT,E,SP)
1-162-282-31 CERAMIC 100PF 10% 50V
1-161-494-00 CERAMIC 0.022uF 5% 25V
1-124-903-11 ELECT 1uF 20% 50V
8-719-110-04 DIODE RD7.5ES-B3
8-719-991-33 DIODE 1SS133T-77
–––––––––––
8-719-991-33 DIODE 1SS133T-77
8-729-040-76 TRANSISTOR KTA1273-Y-AT
1-247-815-91 CARBON 220 5% 1/4W
(US,CND,C&SA)
1-247-807-31 CARBON 100 5% 1/4W
(US,CND,C&SA)
1-249-417-11 CARBON 1K 5% 1/4W
(AEP,IT,E,SP)
1-249-393-11 CARBON 10 5% 1/4W
1-249-429-11 CARBON 10K 5% 1/4W
1-249-421-11 CARBON 2.2K 5% 1/4W
1-249-417-11 CARBON 1K 5% 1/4W
1-249-429-11 CARBON 10K 5% 1/4W
1-249-417-11 CARBON 1K 5% 1/4W
1-249-417-11 CARBON 1K 5% 1/4W
1-762-871-11 SWITCH, KEYBOARD (RESET)
Before Change After Change
Ref. No. Part No. Description Part No. Description Remark
Added
Changed
Added
Changed
Changed
Deleted
Changed
Changed
Changed
Changed
Changed
Changed
Changed
Changed
Changed
Added
Deleted
Added
Changed
Changed
Changed
Added
Added
Added
Added
Added
Added
Added
Changed
MAIN
• Abbreviation
CND : Canadian IT : Italian
C&SA : Central and South America
SP : Singapore
r
CORRECTION
(Service Manual See page 44, 45)
1-161-052-00 CERAMIC 0.012uF 10% 25V
(EXCEPT US,CND)
C23
1-161-055-00 CERAMIC 0.022uF 10% 50V
(US,CND)
1-161-052-00 CERAMIC 0.012uF 10% 25V
(EXCEPT US,CND)
C24
1-161-055-00 CERAMIC 0.022uF 10% 50V
(US,CND)
C56 1-162-290-31 CERAMIC 470PF 10% 50V
C57 1-162-290-31 CERAMIC 470PF 10% 50V
C67 1-162-306-11 CERAMIC 0.01uF 20% 16V
C72 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,IT)
C73 1-162-294-31 CERAMIC 0.001uF 10% 50V
(C&SA)
C77 1-162-207-31 CERAMIC 22PF 5% 50V
JW52 –––––––––––
R12 1-249-426-11 CARBON 5.6K 5% 1/4W
R13 1-249-426-11 CARBON 5.6K 5% 1/4W
R37 1-249-429-11 CARBON 10K 5% 1/4W
1-161-053-00 CERAMIC 0.015uF 10% 25V
(EXCEPT US,CND,C&SA)
1-161-055-00 CERAMIC 0.022uF 10% 50V
(US,CND,C&SA)
1-161-053-00 CERAMIC 0.015uF 10% 25V
(EXCEPT US,CND,C&SA)
1-161-055-00 CERAMIC 0.022uF 10% 50V
(US,CND,C&SA)
1-162-306-11 CERAMIC 0.01uF 20% 16V
1-162-290-31 CERAMIC 470PF 10% 50V
(AEP,IT,E)
–––––––––––
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-162-294-31 CERAMIC 0.001uF 10% 50V
(US,CND,C&SA)
1-162-201-31 CERAMIC 12PF 5% 50V
1-249-429-11 CARBON 10K 5% 1/4W
1-247-843-11 CARBON 3.3K 5% 1/4W
1-247-843-11 CARBON 3.3K 5% 1/4W
–––––––––––
Before Change After Change
Ref. No. Part No. Description Part No. Description Remark
Changed
Changed
Changed
Changed
Deleted
Changed
Changed
Changed
Added
Changed
Changed
Deleted
TUNER
Ref. No. Part No. Description Remark Part No. Description Remark
Page
INCORRECT CORRECT
34,45
55 1-452-899-11 MAGNET
56 3-923-498-01 PLATE, CHUCK
35,45 ! T901 1-426-632-11 TRANS FORMER, POWER (AEP,IT,SP)
3-923-498-01 PLATE, CHUCK
1-452-899-11 MAGNET
1-427-943-11 TRANS FORMER, POWER (AEP,IT,SP)
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une
marque ! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Model Name Using CD Section
NEW
Similar Mechanism Tape Section
Optical Pick-up Type KSM-213CAM/C1NP
Tape Transport Mechanism Type MF-V10-117
Model Name Using CD Section
NEW
Similar Mechanism Tape Section
Optical Pick-up Type KSM-213CDM
Tape Transport Mechanism Type MF-V10-117
New TypeFormer Type
÷
! : changed portion
r
CHANGE OF OPTICAL PICK-UP BLOCK
KSM-213CAM n KSM-213CDM
Since the new chassis assy (MB) (RP), motor (including M702) and chucking plate are not compatible with the former ones, when
replacing either of these parts, replace them with the same version.
How to distinguish the sets
You can distinguish the sets b y the optical pic k-up type name printed on the optical pic k-up b loc k.
Former Type : KSM-213CAM
New Type : KSM-213CD
M
Optical pick-up
Page 1
$
DIFFERENCE PARTS LIST
Ref. No. Part No. Description Remark Part No. Description Remark
Page
Former Type New Type
34 55 3-923-498-01 PLATE, CHUCK (FOR KSM-213CAM)
38
7-6. OPTICAL PICK-UP SECTION
(KSM-213CAM/C1NP)
38,45
255 X-2625-770-1 CHASSIS ASSY (MB) (RP), MOTOR
(INCLUDING M702) (SPINDLE)
3-019-395-01 PLATE, CHUCKING (FOR KSM-213CDM)
7-6. OPTICAL PICK-UP SECTION
(KSM-213CDM)
X-2626-202-1 CHASSIS ASSY (MB) (RP), MOTOR
(INCLUDING M702) (SPINDLE)
