Parts Identification
5
CD 3 (8, 9, 14)
CLOCK/TIMER qg (7, 15, 17)
DISPLAY qh (9, 11)
MEGA BASS 2 (16)
MUSIC MENU wa (16)
PLAY MODE/RDS (European
model only)/DIR qj (8, 9, 12,
13, 14, 15)
PRESET +/– qk (10, 11)
REPEAT 7 (8)
SLEEP qd (17)
TAPE w; (13)
TIMER ON/OFF qf (15, 18)
TUNER/BAND 5 (10, 11, 14)
TUNER MEM/ENTER 6 (7, 9,
10, 12, 15, 17, 18)
TUNING/CLOCK/TIMER +/–
ql (7, 10, 11, 12, 15, 17, 18)
VOLUME +/– 4
BUTTON DESCRIPTIONS
M (fast forward) > (go
forward) 0 (8, 9, 13)
. (go back) m (rewind) qa
(8, 9, 13)
X (pause) qs (8, 13)
nN (play) 8 (8, 9, 13, 14, 15)
`/1 (power) 1 (7, 11, 15, 18)
x (stop) 9 (8, 9, 13, 14)
Remote Control
1234
5
6
7
8
9
q;
qa
qs
qg
qd
qf
qh
qj
qk
ql
w;
wa
To Next Page
