GB
11
GB
A ON/OFF (Power) button
B Shutter button
C For shooting: W/T (zoom) lever
For viewing: (Index) lever/
(Playback zoom) lever
D Flash
E Self-timer lamp/Smile Shutter
lamp/AF illuminator
F Charge lamp/Light sensor
• The brightness of the LCD
monitor is automatically adjusted
to the ambient lighting conditions
using the light sensor.
Do not cover the light sensor with
your hand and so on.
G Microphone
H Lens
I Speaker
J LCD screen
K (Playback) button
L Mode lamp
M Mode button
N Hook for wrist strap
O / (In-Camera Guide/Delete)
button
P MENU button
Q Control button
MENU on: v/V/b/B
MENU off: (Self-Timer)/
(Flash)
R Memory card slot
S Access lamp
T Battery/Memory card cover
U Battery eject lever
V Battery insertion slot
W USB / A/V OUT terminal
X Tripod socket hole
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
Identifying parts
