25
D-NE10
Pin No. Pin Name I/O Description
100 SFDR O
Sled servo drive signal (+) output to the
IC401
101 SSTP I
Disc inner position detection signal input terminal Not used
102 MDS O
Spindle motor drive signal output to the spindle motor driver
103 MDP O
Spindle motor servo control signal output to the spindle motor driver
104 C176 O
176.4 kHz clock output to the power control and spindle motor driver
105
VDD2 — Power supply terminal (digital system)
106 LRCK O
L/R sampling clock (44.1 kHz) output terminal
107 LRCKI I
L/R sampling clock (44.1 kHz) input terminal
108 PCMD O
Serial data output terminal
109 PCMDI I
Serial data input terminal
110 BCKO O
Bit clock (2.8224 MHz) output terminal
111 BCKI I
Bit clock (2.8224 MHz) input terminal
112
DVDD — Power supply terminal (for D-RAM interface)
113 to 117 A3 to A0, A10 O
Address signal output to the D-RAM
118 to 12
A11 to A13 O
Address signal output terminal to the D-RAM Not used
