Sony D-NE10 - Main Board (Side B)

1717
D-NE10
5-3. PRINTED WIRING BOARDS – MAIN BOARD (SIDE B) –
• : Uses unleaded solder.
✩When IC802 is damaged, replace the MAIN board.
IC401
IC602
IC601
IC801
IC702
IC701
IC301
IC403
IC802
13
54
E
E
E
E
E
E
E
u
x
>
.
ON
OFF
S812
(OPEN/CLOSE)
12
A
B
C
D
E
F
G
3456789
MAIN BOARD
(SIDE B)
(11)
11
PROGRAMMER
> HOLD
VOL
1-860-218-
Ref.No. Location
D302 F-4
D304 G-5
D305 F-4
D306 F-4
D308 G-5
D401 E-2
D402 E-2
D403 C-2
D404 D-2
D405 B-3
D406 C-4
D805 E-7
IC301 E-3
IC401 C-2
IC403 C-4
IC601 E-5
IC602 D-4
IC701 A-4
IC702 B-5
IC801 D-7
IC802 B-7
Q301 E-4
Q302 E-3
Q303 E-2
Q401 E-2
Q402 E-2
Q403 D-3
Q404 D-3
Q405 D-3
Q406 B-3
Q801 E-6
Q803 B-3
• Semiconductor
Location
MAIN BOARD
(SIDE B)
