Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
32
D-NE10
MAIN
C605 1-164-858-11 CERAMIC CHIP 22PF 5.00% 50V
C606 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C607 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C608 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C609 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C610 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C611 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V
C612 1-115-156-11 CERAMIC CHIP 1uF 10V
C613 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V
C614 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V
C615 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V
C616 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V
C617 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V
C619 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C620 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V
C621 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C622 1-164-858-11 CERAMIC CHIP 22PF 5.00% 50V
C623 1-115-156-11 CERAMIC CHIP 1uF 10V
C625 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C627 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C628 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C629 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C632 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C702 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C703 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C704 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C706 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C708 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C709 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C710 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C711 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C712 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C713 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C714 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C715 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V
C716 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C717 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C718 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C719 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C720 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C801 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C802 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C803 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C804 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C805 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C806 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C807 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C808 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C809 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C810 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C811 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C812 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C814 1-115-156-11 CERAMIC CHIP 1uF 10V
C815 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
< CONNECTOR >
* CN602 1-785-877-21 HOUSING, CONNECTOR 4P
CN603 1-784-342-21 HOUSING, CONNECTOR 2P
CN604 1-818-127-11 CONNECTOR, FFC/FPC 15P (ZIF L)
< DIODE >
D101 8-719-422-37 DIODE MA8051-TX
D202 8-719-422-37 DIODE MA8051-TX
D302 8-719-046-91 DIODE MA2S111-TX
D303 8-719-422-37 DIODE MA8051-TX
D304 8-719-422-37 DIODE MA8051-TX
D305 8-719-422-37 DIODE MA8051-TX
D306 8-719-422-37 DIODE MA8051-TX
D308 8-719-422-37 DIODE MA8051-TX
D401 6-500-483-01 DIODE MA22D2800LS0
D402 8-719-085-43 DIODE MA2YD2300LS0
D403 8-719-071-87 DIODE MA785-(TX),SO
D404 8-719-071-87 DIODE MA785-(TX),SO
D405 8-719-072-70 DIODE MA2ZD14001S0
D406 8-719-404-50 DIODE MA111-TX
D804 6-500-781-01 DIODE SML-521MUW (OPR)
D805 6-500-473-01 DIODE MA4SD0100LS0
< FERRITE BEAD >
FB301 1-414-813-11 FERRITE 0uH
FB302 1-414-813-11 FERRITE 0uH
FB402 1-216-864-11 METAL CHIP 0 5% 1/16W
FB601 1-414-760-21 FERRITE 0uH
FB602 1-216-864-11 METAL CHIP 0 5% 1/16W
FB603 1-216-864-11 METAL CHIP 0 5% 1/16W
FB604 1-414-760-21 FERRITE 0uH
FB605 1-216-864-11 METAL CHIP 0 5% 1/16W
FB701 1-414-760-21 FERRITE 0uH
FB706 1-414-760-21 FERRITE 0uH
< IC >
IC301 6-705-414-01 IC AN17020B-E1
IC401 6-600-327-01 IC TB2166FG
* IC403 6-703-107-01 IC SN74LVC2G66DCUR
IC601 8-752-420-71 IC CXD3039AR
IC602 6-702-737-01 IC MSM51X17400F-10TFSR1
IC602 6-704-280-01 IC 41SV44052-100TG
IC701 6-550-559-01 TRANSISTOR XN0NE9200LS0
IC702 8-753-210-87 IC CXR710160-207R
IC801 6-803-671-01 IC TMP91CY28FG-2772-01
✩ IC802 ---------------- IC AK6417CH-E2
< JACK >
J401 1-815-912-21 JACK, DC (EXT BATT)
J402 1-815-912-21 JACK, DC (CHARGING STAND)
< COIL >
L301 1-469-967-21 INDUCTOR 10uH
L302 1-400-317-21 INDUCTOR 100uH
L401 1-412-056-11 INDUCTOR 4.7uH
L402 1-412-056-11 INDUCTOR 4.7uH
L403 1-469-967-21 INDUCTOR 10uH
L404 1-400-317-21 INDUCTOR 100uH
L405 1-414-434-11 INDUCTOR 100uH
L406 1-400-145-21 INDUCTOR 47uH
L407 1-400-145-21 INDUCTOR 47uH
L408 1-419-188-41 INDUCTOR 100uH
✩When IC802 is damaged, replace the MAIN board.
