12
D-NE730/NE730LS/NE830/NE830LS
Ref. No. Part No. Description Remark
< COMPOSITION CIRCUIT BLOCK >
RB301 1-233-788-11 RES, NETWORK 2.2K (1608)
RB601 1-233-969-11 RES, NETWORK (CHIP TYPE) 22K
< SWITCH >
S501 1-771-105-11 SWITCH, TACTILE (u)
S502 1-771-105-11 SWITCH, TACTILE (>)
S503 1-771-105-11 SWITCH, TACTILE (.)
S504 1-771-105-11 SWITCH, TACTILE ( +)
S505 1-771-105-11 SWITCH, TACTILE ( –)
S506 1-771-105-11 SWITCH, TACTILE (x/CHG)
S507 1-771-105-11 SWITCH, TACTILE (VOL +)
S508 1-771-105-11 SWITCH, TACTILE (VOL –)
S801 1-762-805-41 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
S802 1-572-922-11 SWITCH, SLIDE (HOLD .)
< THERMISTOR >
TH401 1-805-719-11 THERMISTOR, POSITIVE
< VARISTOR >
VDR401 1-801-864-21 VARISTOR, CHIP (1608)
< VIBRATOR >
X601 1-795-392-21 VIBRATOR, CERAMIC 22MHz
MAIN
