15
US
Getting Started
Step 1: Assembling the Speakers
Before connecting the speakers, attach the speaker stand to the speaker.
(For the front speakers of DAV-HDX575WC/DAV-HDX578W/DAV-HDX678WF, front and
surround speakers of DAV-HDX975WF)
Use the parts as follows:
DAV-HDX575WC/DAV-HDX578W/DAV-HDX678WF
• Front speakers (2)
• Speaker cords (2, red/white)
•Posts (2)
• Bases (2)
• Mounting plates (2)
• Post covers (2)
• Screws (large, with washer) (4)
• Screws (small) (6)
DAV-HDX975WF
• Front and surround speakers (4)
• Speaker cords (4, red/white/blue/gray)
•Posts (4)
• Bases (4)
• Mounting plates (4)
• Post covers (4)
• Screws (large, with washer) (8)
• Screws (small) (12)
Although the rear layout of the front speaker is slightly different from it of the surround speaker, the
way of the assembling is the same. (The illustrations in the following steps are for the front speakers
as example.)
About how to connect the speaker cords to the SPEAKER jacks, see page 29.
Note
• Spread a cloth on the floor to avoid damaging the floor when you assemble the speakers.
Ti
• You can use the speaker without the speaker stand by installing it on the wall (page 21).
To Next Page
