— 2 —
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
51 X-2023-770-1 PANEL ASSY, FRONT (EXCEPT HC17E)
154 2-188-434-01 COVER (C), HINGE
162 X-2024-694-1 CABINET R ASSY
(HC22E/HC32/HC32E/HC33/HC33E)
169 2-188-432-71 CABINET (C)103, P (HC33E)
51 X-2023-770-1 PANEL ASSY, FRONT
(SILVER) (EXCEPT HC17E)
51 X-2048-775-1 PANEL ASSY, FRONT (GREEN) (HC33E)
51 X-2048-776-1 PANEL ASSY, FRONT (PINK) (HC33E)
154 2-188-434-01 COVER (C), HINGE (SILVER)
154 2-188-434-21 COVER (C), HINGE (GREEN) (HC33E)
154 2-188-434-31 COVER (C), HINGE (PINK) (HC33E)
162 X-2024-694-1 CABINET R ASSY
(SILVER) (HC22E/HC32/HC32E/HC33/HC33E)
162 X-2048-772-1 CABINET R ASSY (GREEN) (HC33E)
162 X-2048-773-1 CABINET R ASSY (PINK) (HC33E)
169 2-188-432-71 CABINET (C) 103, P (SILVER) (HC33E)
169 2-188-456-01 CABINET (C) 103, P (GREEN) (HC33E)
169 2-188-456-11 CABINET (C) 103, P (PINK) (HC33E)
5-1. EXPLODED VIEWS
&: Points added portion.
Page Former New
Ref. No. Part No. DescriptionRef. No. Part No. Description
5-3
109 2-318-138-01 RUBBER, SEAL
5-1. EXPLODED VIEWS
&: Points added portion.
-: Points changed portion.
Page Former New
Ref. No. Part No. DescriptionRef. No. Part No. Description
5-4
5-5
•Addition of Green and Pink Models (HC33E)
•Change of Repair Parts
CD-533
IC101
(Note1, 2)
ns
104
105
106
CD-533
IC101
(Note1, 2)
104
105
106
109
[
*
*
)
*
)
)
)
*
*
*
*
*
*
