DCR-PC109/PC109E
HELP
2
Unwind the FP-848 flexible
board wide open.
4
FP-848 flexible board
3
Hinge (63) assembly
1
Peel off the adhesive surface.
Harness (RR-057)
Cutout of the control switch block (ZM6800)
Adhesive surface
HELP 03
HELP 02
