Sony DCR-PC109 User Manual

4-85
DCR-PC109/PC109E
CD-494/CR-047/SE-140
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
4-4. MOUNTED PARTS LOCATION
no mark : side A
* mark : side B
CD-494 BOARD
* C201 B-1
* C202 B-1
* C203 A-1
* C204 B-1
* C205 B-2
* C206 A-2
* C207 A-2
* C208 A-2
* C209 A-1
* C210 A-1
* C213 A-2
* C214 A-2
* C215 B-1
* C218 B-1
* C219 B-1
* CN201 A-1
* FB201 B-1
IC201 A-1
* IC202 A-2
* L201 A-2
* L202 B-2
* Q201 B-1
* Q202 A-2
* R201 B-1
* R202 A-1
* R203 A-2
* R204 A-2
* R205 A-2
* R206 A-2
CR-047 BOARD
CN801 A-1
CN802 B-1
CN803 C-1
* D801 C-1
* D802 C-1
* D803 B-1
* D804 B-1
* R801 C-1
* S801 C-1
* S802 B-1
* VDR801 C-1
* VDR802 A-1
* VDR803 A-1
* VDR804 A-1
* VDR805 A-1
* VDR806 A-1
SE-140 BOARD
* C401 B-1
C402 B-2
C403 B-2
* C404 B-1
C405 A-2
C406 A-2
C407 B-2
C408 A-2
C409 B-2
C410 B-2
C411 A-2
C412 A-2
C413 B-2
C414 B-2
C415 B-1
C416 B-1
C417 A-1
* CN401 A-1
CN402 B-1
* FB401 B-1
FB402 B-2
FB403 B-2
FB404 A-2
FB405 A-1
FB406 A-1
FB407 A-1
IC401 B-1
J401 A-2
L401 B-1
* R401 A-1
R402 A-1
R403 A-1
R404 B-1
R405 B-1
R406 B-1
RB401 B-2
* SE401 B-1
* SE402 B-2
* VDR401 A-1
* VDR402 A-1
