5-9
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• Canadian model is abbreviated as CND.
• Tourist model is abbreviated as JE.
5-2. ELECTRICAL PARTS LIST
Note:
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
When indicating parts by reference
number, please include the board
name.
A-7072-919-A CC-97 BOARD, COMPLETE (PC7)
***************************
A-7072-925-A CC-97P BOARD, COMPLETE (PC7E)
*****************************
(Ref. No. 20,000 Series)
< CONNECTOR >
CN6250 1-778-599-21 CONNECTOR, BOARD TO BOARD 80P
CN6251 1-778-594-21 CONNECTOR, BOARD TO BOARD 80P
A-7066-865-A CD-159 BOARD, COMPLETE (PC7)
****************************
A-7066-895-A CD-159P BOARD, COMPLETE (PC7E)
******************************
(IC101 is not included to the mounted board)
(Ref. No. 1,000 Series)
< CAPACITOR >
C100 1-113-986-11 TANTAL. CHIP 2.2uF 20% 25V
C101 1-162-638-11 CERAMIC CHIP 1uF 16V
C102 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C103 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C104 1-135-215-21 TANTAL. CHIP 6.8uF 20% 16V
C105 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C106 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C107 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C108 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C109 1-104-916-11 TANTAL. CHIP 6.8uF 20% 20V
C110 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C500 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C501 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C502 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C503 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C504 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C505 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C506 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C507 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C508 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C509 1-117-155-11 ELECT 33uF 20% 6.3V
C510 1-117-155-11 ELECT 33uF 20% 6.3V
C511 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C512 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C513 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C515 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
CD-159CC-97
C515 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
(PC7E)
C516 1-107-820-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN100 1-778-597-21 CONNECTOR, BOARD TO BOARD 50P
CN101 1-766-359-21 CONNECTOR, FFC/FPC 29P
< DIODE >
D100 8-719-056-23 DIODE MA2S111-(K8).SO
D101 8-719-056-23 DIODE MA2S111-(K8).SO
< FERRITE BEAD >
FB100 1-543-955-11 BEAD, FERRITE (CHIP)
FB101 1-543-955-11 BEAD, FERRITE (CHIP)
< IC >
IC100 8-752-372-14 IC CXD1267AN-T4
IC101 A-7030-755-A CCD BLOCK ASSY (080 SERVICE)
(CCD IMAGER)(PC7)
IC101 A-7030-765-A CCD BLOCK ASSY (081 SERVICE)
(CCD IMAGER)(PC7E)
IC500 8-759-080-34 IC TA75W01FU-TE12R
IC501 8-759-058-45 IC NJM3403AV(TE2)
IC502 8-759-234-77 IC TC4S66F(TE85R)
IC503 8-759-234-77 IC TC4S66F(TE85R)
< COIL >
L500 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q100 8-729-232-86 TRANSISTOR 2SK1875-(TE85L)
< RESISTOR >
R100 1-218-977-11 METAL GLAZE 100K 5% 1/16W
R101 1-218-989-11 METAL GLAZE 1M 5% 1/16W
R102 1-218-937-11 METAL GLAZE 47 5% 1/16W
R103 1-218-956-11 METAL GLAZE 1.8K 5% 1/16W
R500 1-218-969-11 METAL GLAZE 22K 5% 1/16W
R501 1-218-969-11 METAL GLAZE 22K 5% 1/16W
R502 1-218-969-11 METAL GLAZE 22K 5% 1/16W
R503 1-218-969-11 METAL GLAZE 22K 5% 1/16W
R504 1-218-969-11 METAL GLAZE 22K 5% 1/16W
R505 1-218-969-11 METAL GLAZE 22K 5% 1/16W
Be sure to read “Note on the CCD Imager replacement”
on page 4–12 when changing the CCD imager.
