2-2
Ref. No. Part No. Description
Ref. No. Part No. Description
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SX73E/SX83/SX83E, HDR-CX110/CX110E/CX115E/CX116E/CX150/CX150E/CX155E/CX170_L3
< COMPOSITION CIRCUIT BLOCK >
RB7201 1-234-381-11 RES, NETWORK 100K (1005X4)
(EXCEPT CX110/CX110E/CX115E)
RB8701 1-234-381-11 RES, NETWORK 100K (1005X4)
(EXCEPT CX110/CX110E/CX115E)
A-1756-546-A MS-431 BOARD, COMPLETE
**********************
(BT7301 (LITHIUM ION BATTERY) is not included in MS-431 complete board.)
< BATTERY HOLDER >
 BH7301 1-756-615-61 HOLDER, BATTERY (Note)
< BATTERY >
 BT7301 1-756-134-12 LITHIUM ION BATTERY (Note)
< CAPACITOR >
* C6615 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C6616 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C6617 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C6618 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6619 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C6620 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C6621 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C6622 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C6623 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C6624 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C6625 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C6626 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
* C6627 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
* C7301 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C7303 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C7304 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7306 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7308 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
< CONNECTOR >
* CN7301 1-820-729-61 CONNECTOR, FPC (ZIF) 51P
CN7303 1-816-645-61 FFC/FPC CONNECTOR (LIF) 14P
CN7304 1-822-837-21 CARD CONNECTOR
< DIODE >
D7301 6-501-216-01 DIODE CL-271HR-C-TS
< FERRITE BEAD >
FB7301 1-481-377-21 FERRITE, EMI (SMD)
< IC >
IC6601 6-707-333-01 IC NJM3230SE7
* IC7301 6-714-502-01 IC BD2224G-TR
* IC7303 6-714-502-01 IC BD2224G-TR
< COIL >
L6602 1-400-588-11 INDUCTOR 10uH
< RESISTOR >
R6604 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6605 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6606 1-208-711-11 METAL CHIP 15K 0.50% 1/16W
R6607 1-218-985-11 METAL CHIP 470K 5% 1/16W
R6608 1-218-985-11 METAL CHIP 470K 5% 1/16W
R6609 1-208-711-11 METAL CHIP 15K 0.50% 1/16W
R7301 1-218-949-11 METAL CHIP 470 5% 1/16W
R7302 1-218-945-11 METAL CHIP 220 5% 1/16W
R7303 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R7304 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R7305 1-218-945-11 METAL CHIP 220 5% 1/16W
R7307 1-218-943-11 METAL CHIP 150 5% 1/16W
R7308 1-218-943-11 METAL CHIP 150 5% 1/16W
R7309 1-218-943-11 METAL CHIP 150 5% 1/16W
R7311 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R7320 1-218-943-11 METAL CHIP 150 5% 1/16W
R7322 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R7329 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7330 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7331 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7332 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7333 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7336 1-218-941-81 METAL CHIP 100 5% 1/16W
R7337 1-218-941-81 METAL CHIP 100 5% 1/16W
R7338 1-218-941-81 METAL CHIP 100 5% 1/16W
R7339 1-218-941-81 METAL CHIP 100 5% 1/16W
R7340 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7341 1-218-941-81 METAL CHIP 100 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB6601 1-234-379-21 RES, NETWORK 22K (1005X4)
RB7303 1-234-378-21 RES, NETWORK 10K (1005X4)
RB7305 1-234-381-11 RES, NETWORK 100K (1005X4)
< SWITCH >
S7302 1-798-119-11 SWITCH, TACTILE
S7304 1-798-119-11 SWITCH, TACTILE
S7305 1-798-119-11 SWITCH, TACTILE
S7306 1-798-119-11 SWITCH, TACTILE
< SENSOR >
* SE6602 1-479-022-51 SENSOR, ANGULAR VELOCITY (30.8kHz) (PITCH)
* SE6603 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2kHz) (YAW)
A-1757-118-A VC-590 BOARD, COMPLETE(SERVICE)
(CX110/CX110E/CX150/CX150E/CX170)
A-1757-119-A VC-590 BOARD, COMPLETE(SERVICE)
(SX83/SX83E)
A-1757-122-A VC-590 BOARD, COMPLETE(SERVICE)
(CX115E/CX116E/CX155E)
A-1757-123-A VC-590 BOARD, COMPLETE(SERVICE)
(SX73E)
******************************
(IC7501 and IC8101 are not supplied, but there are included in VC-590 complete
board (service).)
< CAPACITOR >
C1005 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1008 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1011 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1014 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(EXCEPT CX110/CX115E)
* C1015 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT CX110/CX115E)
* C1016 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2205 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C2206 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C2207 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C2208 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C2209 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
* C2210 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2211 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2212 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2216 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
C2217 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C2218 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
(EXCEPT SX73E/SX83/SX83E)
* C2219 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2220 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2228 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2229 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2231 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2233 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2235 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2236 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2239 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2240 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2242 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
C2301 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
* C2302 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2303 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2304 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C2305 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
C2401 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
* C2402 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C2403 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2404 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
* C2405 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2406 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2407 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2409 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2410 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2411 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2412 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
* C2413 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
* C2414 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2415 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2416 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
* C2417 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2420 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2422 1-100-844-91 TANTAL. CHIP 22uF 20% 10V
C2501 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C2502 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2503 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2504 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2505 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
* C2506 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C2507 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
* C2508 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C3501 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
C3503 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SX73E/SX83/SX83E)
* C3504 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C3505 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
* C3506 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
C3507 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
C3508 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
(EXCEPT SX73E/SX83/SX83E)
C3509 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT SX73E/SX83/SX83E)
C4604 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4605 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4606 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4701 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4703 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4704 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4705 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4706 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4708 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4711 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4713 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4714 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4715 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
VC-590MS-431JK-395
To Next Page
