Sony DCR-SX73E - Repair Parts List

2-1
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SX73E/SX83/SX83E, HDR-CX110/CX110E/CX115E/CX116E/CX150/CX150E/CX155E/CX170_L3
2. REPAIR PARTS LIST
A-1756-539-A CM-114 BOARD, COMPLETE
********************
(CP002(CMOS imager) is not supplied, but this is included in CM-114 complete
board.)
< CAPACITOR >
C6903 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6905 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6907 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6908 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
* C6909 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6910 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
* C6912 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6914 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6915 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6916 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
* C6917 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6920 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6921 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6923 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6924 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6925 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6927 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6928 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6930 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6932 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
* C6933 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C6935 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C6936 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6939 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
* C6940 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6941 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN6901 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
< COMPOSITION CIRCUIT BLOCK >
CP002 (Not supplied) IMX055CHL-13
(CP002 is supplied included in CM-114 complete board.)
< IC >
* IC6902 6-708-455-01 IC R1114Q271D-TR-FA
< LINE FILTER >
* LF6901 1-457-648-21 COMMON MODE CHOKE COIL
* LF6902 1-457-648-21 COMMON MODE CHOKE COIL
* LF6903 1-457-648-21 COMMON MODE CHOKE COIL
* LF6904 1-457-648-21 COMMON MODE CHOKE COIL
* LF6905 1-457-648-21 COMMON MODE CHOKE COIL
< RESISTOR >
R6915 1-216-864-11 SHORT CHIP 0
R6919 1-208-927-11 METAL CHIP 47K 0.50% 1/16W
R6932 1-218-953-11 METAL CHIP 1K 5% 1/16W
A-1756-550-A JK-395 BOARD, COMPLETE
(CX110/CX110E/CX115E)
A-1756-548-A JK-395 BOARD, COMPLETE
(CX150/CX150E/CX155E)
A-1756-549-A JK-395 BOARD, COMPLETE
(SX73E/SX83/SX83E)
A-1756-550-A JK-395 BOARD, COMPLETE (CX116E)
A-1761-893-A JK-395 BOARD, COMPLETE (CX170)
**********************************
(IC8701 is not supplied, but this is included in JK-395 complete board.)
< CAPACITOR >
C8701 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
(EXCEPT CX110/CX110E/CX115E)
* C8702 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT CX110/CX110E/CX115E)
* C8705 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT CX110/CX110E/CX115E)
< CONNECTOR >
* CN7201 1-819-572-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 30P
CN7202 1-822-425-21 CONNECTOR, USB (MINI AB)
CN7203 1-821-166-21 HDMI CONNECTOR
(EXCEPT CX110/CX110E/CX115E)
* CN7204 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
(EXCEPT CX110/CX110E/CX115E)
< CONTACT TERMINAL >
ET7201 1-780-638-22 CONTACT TERMINAL
< IC >
* IC8701 6-713-616-01 IC THGBM1G7D8EBAI0
(SX73E/SX83/SX83E/CX150/CX150E/CX155E)
* IC8701 6-713-703-01 IC THGBM1G6D4EBAI4 (CX116E)
IC8701 (Not supplied) IC THGBM1G8D8EBAI2 (CX170)
(IC8701 is supplied including in JK-395 complete board.)
< RESISTOR >
R7207 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7208 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7209 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7210 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7211 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7212 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7213 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7214 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R7215 1-218-937-11 METAL CHIP 47 5% 1/16W
(EXCEPT CX110/CX110E/CX115E)
R8701 1-218-990-81 SHORT CHIP 0
(EXCEPT CX110/CX110E/CX115E)
R8702 1-218-990-81 SHORT CHIP 0
(EXCEPT CX110/CX110E/CX115E)
JK-395
2-2. ELECTRICAL PARTS LIST
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some
differences from the original one.
• Items marked “*” are not stocked since they are seldom re-
quired for routine service. Some delay should be anticipated
when ordering these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may
be different from the parts specified in the diagrams or the
components used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は, 補修用部品であるため,回路
図及びセットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため,セットに付いている部品と異な
る場合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれ
μA...,μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0
印の部品，または
0
印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
When indicating parts by reference
number, please include the board name.
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
Note1 : Be sure to read “Precautions for Replacement of
Imager” on page 6-1 when changing the imager.
Note1 :
 イメージャの交換時は6-1ページの“イメージャ交換
時の注意”を必ずお読みください。
CM-114
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
Note:
Replace the battery holder (BH7301) together when
replacing the lithium ion battery (BT7301) on the
MS-431 board. (The battery holder removed once
cannot be used again.)
When mounting these parts, mount new battery
holder first and attach new lithium battery next.
Note:
MS-431基板のリチウム蓄電池（BT7301）を交換す
る場合はバッテリホルダ（BH7301）も同時に新品に
交換して下さい。（一度使用したバッテリホルダは
再使用できません。）
 部品取り付けの際は，先にバッテリホルダを取り
付けてからリチウム電池を装着して下さい。
