9-42
DFP-3000
1. Connecting DA-20 to the AUX1 input terminal
2. Connecting DA-20 to the AUX2 input terminal
Pin 1 (Ctri 0)
Pin 14 (Senced)
Pin 12 (GND)
Pin 34 (Lip +.
AUX1 Active)
Pin 14 (Logic Common)
Automation
Input /Output
AUX1 Input
D-sub 25 pin
Connector
D-sub 37 pin
Connector
D-sub 25 pin
Connector
D-sub 25 pin
Connector
Dolby Laboratories, Inc. DA-20 DFP-D3000
CP Audio
Connector (J8)
Sence / Contorl (J6)
Pin 1 (Ctri 0)
Pin 14 (Senced)
Pin 12 (GND)
Pin 35 (Lip +.
AUX1 Active)
Pin 14 (Logic Common)
Automation
Input /Output
AUX2 Input
D-sub 25 pin
Connector
D-sub 37 pin
Connector
D-sub 25 pin
Connector
D-sub 25 pin
Connector
Dolby Laboratories, Inc. DA-20 DFP-D3000
CP Audio
Connector (J8)
Sence / Contorl (J6)
