DSC-H300
– 2 –
SPECIFICATIONS
Camera
[System]
Image device: 7.76 mm (1/2.3 type) CCD,
Primary color filter
Total pixel: Approx. 20.4 Megapixels
Effective pixel: Approx. 20.1 Megapixels
Lens: 35× zoom lens
f = 4.5 mm – 157.5 mm (25 mm – 875 mm
(35 mm film equivalent))
F3.0 (W) – F5.9 (T)
While shooting movies (16:9):
30.3 mm – 1 060 mm
While shooting movies (4:3):
27.8 mm – 973 mm
SteadyShot: Optical
Burst shooting (when shooting with the largest
pixel number):
Approx. 0.80 images/second (up to 100 im-
ages)
File format:
Still images: JPEG (DCF, Exif, MPF Baseline)
compliant, DPOF compatible
Movies: MPEG-4 AVC/H.264
Recording media: Internal Memory (Approx. 55
MB), “Memory Stick Duo” media, “Memory
Stick Micro” media, SD cards, microSD
memory cards
Flash: Flash range (ISO sensitivity (Recommended
Exposure Index) set to Auto):
Approx. 0.4 m to 6.8 m (1.3 ft. to 22.3 ft.) (W)
Approx. 1.5 m to 3.6 m (4.9 ft. to 11.8 ft.) (T)
[Input and Output connectors]
USB / A/V OUT jack:
Video output
Audio output
USB communication
USB communication: Hi-Speed USB (USB 2.0)
[Screen]
LCD screen: 7.5 cm (3.0 type) TFT drive
Total number of dots: 460 800 dots
[Power, general]
Power: LR6 (size AA) alkaline batteries (4), 6 V
HR15/51: HR6 (size AA) Nickel-Metal Hy-
dride batteries (4) (sold separately), 4.8 V
Power consumption (during shooting):
Approx. 1.6 W
Operating temperature: 0°C to 40°C
(32°F to 104°F)
Storage temperature: –20°C to +60°C
(–4°F to +140°F)
Dimensions (CIPA compliant):
127.5 mm × 89.0 mm × 91.7 mm (5 1/8 inches
× 3 5/8 inches × 3 5/8 inches) (W/H/D)
Mass (CIPA compliant) (including four batteries
and “Memory Stick Duo” media):
Approx. 590 g (1 lb 4.8 oz)
Microphone: Monaural
Speaker: Monaural
Exif Print: Compatible
PRINT Image Matching III: Compatible
Design and specifications are subject to change
without notice.
Model information table
Model DSC-H300
Destination US, CND, E, BR AEP, UK, RU, E, CH
Color system NTSC PAL
GPS – –
• Abbreviation
BR : Brazilian model
CH : Chinese model
CND : Canadian model
RU : Russian model
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH
MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 350°C during
repairing.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
Caution
Danger of explosion occurs if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350°C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。
