When using the viewfinder
To store the viewfinder
Push down the top of the viewfinder.
Battery insertion slot30.
Battery lock lever31.
Tripod socket hole
Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the camera,
and damage to the camera may occur.
32.
Access lamp33.
Memory card slot34.
Battery/Memory card cover35.
Speaker36.
Slide down the viewfinder pop-up switch.
If you slide the viewfinder pop-up switch when the power is off, the camera turns on.
To choose whether or not to turn the camera off when the viewfinder is stowed, select MENU →
(Setup) →
[Function for VF close].
1.
Adjust the diopter-adjustment lever to your eyesight until the display appears clearly in the viewfinder.2.
