Sony DSC-TX9 - Repair Parts List; Electrical Parts List

DSC-TX9/TX9C_L3
2-1
Ref. No. Part No. DescriptionRef. No. Part No. Description
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
When indicating parts by reference num-
ber, please include the board name.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une mar-
que 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Note: Be sure to read “Precautions for Replacement
of Imager” on page 6-1.
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため,セットに付いている部品と異なる場
合があります。
•
*
印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμA...,
μPA...,μPB...,μPC...,μPD...を示します。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
0
印の部品，または
0
印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
Note:
 イメージャの交換時は6-1ページの“イメージャ
交換時の注意”を必ずお読みください。
2. REPAIR PARTS LIST
A-1786-580-A CD-800 FLEXIBLE BOARD
********************
(All mounted parts are not supplied, but they are included in CD-800 FLEXIBLE
COMPLETE BOARD.)
^
A-1786-717-A SY-236 COMPLETEBOARD (SERVICE)
*********************
(CN701, CN704 and IC211 are not supplied, but they are included in SY-236 COMPLETE
BOARD (SERVICE).)
< CAPACITOR >
C004 1-114-098-91 CERAMIC CHIP 2.2uF 20% 25V
C011 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C013 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C014 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C016 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C018 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C020 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C021 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C023 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C024 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C025 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C026 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
C029 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
* C030 1-114-795-21 TANTAL. CHIP 22uF 20% 10V
C036 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
* C037 1-112-864-81 CERAMIC CHIP 14PF 5% 50V
C038 1-128-605-11 CERAMIC CHIP 12PF 5% 25V
C041 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C043 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C050 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C051 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C202 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
* C207 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C208 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C209 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C212 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C216 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C217 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C219 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C220 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
* C226 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C227 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
* C232 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C233 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C236 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C237 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C255 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C257 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C261 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
* C263 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C264 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C265 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C267 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C269 1-116-765-91 CERAMIC CHIP 0.1uF 10% 6.3V
* C270 1-116-765-91 CERAMIC CHIP 0.1uF 10% 6.3V
* C271 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C274 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C277 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C280 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C281 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C283 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C355 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C357 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C358 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C365 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C366 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C367 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C368 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C370 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C372 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C373 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C374 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C401 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C402 1-128-628-91 CERAMIC CHIP 0.0022uF 10% 6.3V
C403 1-128-628-91 CERAMIC CHIP 0.0022uF 10% 6.3V
C405 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C406 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C407 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C410 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C411 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
C412 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
* C414 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C415 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C417 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
* C418 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
* C419 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C420 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C421 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C490 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C493 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
* C495 1-112-678-91 CERAMIC CHIP 0.068uF 20% 6.3V
* C496 1-112-678-91 CERAMIC CHIP 0.068uF 20% 6.3V
C497 1-100-965-91 CERAMIC CHIP 0.047uF 10% 6.3V
C498 1-100-965-91 CERAMIC CHIP 0.047uF 10% 6.3V
C501 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C504 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C506 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C507 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C510 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
C511 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
C513 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C514 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C515 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
* C518 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C519 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C601 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C604 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C605 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C607 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
* C608 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
* C611 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C702 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
* C704 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C705 1-100-965-91 CERAMIC CHIP 0.047uF 10% 6.3V
C708 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
SY-236
2-2. ELECTRICAL PARTS LIST
CD-800
