5-8
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-W1/W12
MS-204 MS-205
< RESISTOR >
R801 1-218-975-11 RES-CHIP 68K 5% 1/16W
R804 1-208-933-11 METAL CHIP 82K 0.5% 1/16W
R805 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R807 1-218-953-11 RES-CHIP 1K 5% 1/16W
R808 1-218-977-11 RES-CHIP 100K 5% 1/16W
R809 1-218-990-11 SHORT CHIP 0
R810 1-218-990-11 SHORT CHIP 0
R811 1-218-969-11 RES-CHIP 22K 5% 1/16W
R825 1-218-989-11 RES-CHIP 1M 5% 1/16W
R826 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R830 1-208-677-11 METAL CHIP 560 0.5% 1/16W
R831 1-208-677-11 METAL CHIP 560 0.5% 1/16W
R832 1-208-677-11 METAL CHIP 560 0.5% 1/16W
R901 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R902 1-218-981-11 RES-CHIP 220K 5% 1/16W
R903 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R911 1-216-864-11 SHORT CHIP 0
R912 1-218-953-11 RES-CHIP 1K 5% 1/16W
R913 1-218-953-11 RES-CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB801 1-234-369-21 RES, NETWORK 10 x4 (1005)
< SWITCH >
S901 1-786-227-21 SWITCH, TACTILE (RESET)
A-7079-040-A MS-205 FLEXIBLE BOARD, COMPLETE
*******************************
(This complete board is including JK-263 board,
MS-204 board and SP-045 flexible board.)
1-862-488-11 SP-045 FLEXIBLE BOARD
< CONNECTOR >
CN001 1-778-597-21 CONNECTOR, BOARD TO BOARD 50P
< JACK >
J101 1-793-620-41 JACK (AV OUT (MONO))
0 J102 1-817-331-11 DC JACK 5P (DC IN)
< SPEAKER >
SP901 1-825-219-21 SPEAKER (1.3CM)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver. 1.4 2007.10
The changed portions from
Ver. 1.3 are shown in blue.
