Sony DSC-W1 - Page 27

5-10
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-W1/W12
SW-422 SY-102
A-7079-041-A SW-422 BOARD, COMPLETE
***********************
< CAPACITOR >
C151 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C152 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C153 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C154 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C155 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C156 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C159 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C160 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C161 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C162 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C163 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C166 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C167 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C168 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C169 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
< CONNECTOR >
CN101 1-784-421-11 FFC/CONNECTOR, FPC (ZIF) 27P
CN102 1-794-375-21 PIN, CONNECTOR 2P
< DIODE >
D203 6-500-776-01 DIODE MAZW068H0LS0
< IC >
IC151 6-705-754-01 IC BH6413GLU-E2
< COIL >
L152 1-469-757-21 INDUCTOR 10uH
< RESISTOR >
R151 1-218-990-11 SHORT CHIP 0
R152 1-218-967-11 RES-CHIP 15K 5% 1/16W
R153 1-218-989-11 RES-CHIP 1M 5% 1/16W
R155 1-218-989-11 RES-CHIP 1M 5% 1/16W
R156 1-218-990-11 SHORT CHIP 0
R157 1-218-969-11 RES-CHIP 22K 5% 1/16W
R203 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R204 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R205 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R206 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R207 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R208 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
< SWITCH >
S201 1-786-157-11 SWITCH, TACTILE (v (FLASH))
S202 1-786-157-11 SWITCH, TACTILE (b (REVIEW))
S203 1-786-157-11 SWITCH, TACTILE (z (SET))
S204 1-786-157-11 SWITCH, TACTILE (V (SELF TIMER))
S205 1-786-157-11 SWITCH, TACTILE (B (MACRO))
S206 1-786-157-11 SWITCH, TACTILE (MENU)
S207 1-786-157-11 SWITCH, TACTILE (DISPLAY / LCD ON/OFF)
S208 1-786-157-11 SWITCH, TACTILE (IMAGE SIZE/DELETE)
A-1065-212-A SY-102 BOARD, COMPLETE (SERVICE)
*******************************
(This complete board is including CP101 (CH-146 board)
and IC301 (KWF board).)
< CAPACITOR >
C001 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C002 1-128-630-91 CERAMIC CHIP 0.0047uF 10% 6.3V
C003 1-128-630-91 CERAMIC CHIP 0.0047uF 10% 6.3V
C004 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C005 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C006 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C008 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C009 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C010 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C016 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C017 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C018 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C019 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C020 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C021 1-128-627-91 CERAMIC CHIP 0.001uF 10% 16V
C022 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C023 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C024 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C025 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C026 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C027 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C028 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C029 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C030 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C031 1-100-671-11 CERAMIC CHIP 4.7uF 20% 25V
C032 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
C033 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C034 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C035 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C036 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C037 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C038 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C039 1-100-672-11 CERAMIC CHIP 10uF 20% 16V
C045 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C046 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C047 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C049 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C051 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C052 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C053 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C054 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C055 1-100-671-11 CERAMIC CHIP 4.7uF 20% 25V
C056 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C057 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C058 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C059 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C060 1-135-941-11 CERAMIC CHIP 22uF 10% 6.3V
C061 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C101 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C102 1-137-988-91 CERAMIC CHIP 1uF 10% 35V
C103 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C104 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C106 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C108 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C109 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
