5-11
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-W1/W12
C110 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C111 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C113 1-137-910-11 TANTAL. CHIP 10uF 20% 16V
C201 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C203 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C211 1-100-663-11 TANTAL. CHIP 22uF 20% 10V
C301 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C302 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C305 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C306 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C309 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C310 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C311 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C312 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C313 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C314 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C315 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C316 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C317 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C318 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C319 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C321 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C322 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C323 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C324 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C325 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C326 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C327 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C328 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C330 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C331 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C332 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C333 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C334 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C338 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C339 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C340 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C341 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C342 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C344 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C345 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C346 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C347 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C348 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C349 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C401 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C402 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C406 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C407 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C408 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C409 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C410 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C411 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C503 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C505 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C506 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C507 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C508 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C509 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C510 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C511 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C529 1-127-578-91 TANTAL. CHIP 3.3uF 20% 6.3V
C530 1-128-627-91 CERAMIC CHIP 0.001uF 10% 16V
C531 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C532 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C535 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C536 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C537 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C538 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C539 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C540 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C541 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C543 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C544 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C545 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C546 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C602 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C603 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C604 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C606 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C701 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN001 1-817-705-11 CONNECTOR, FPC 10P
CN201 1-815-332-11 CONNECTOR, FPC (ZIF) 31P
CN601 1-815-097-11 CONNECTOR, FPC (ZIF) 17P
CN701 1-816-057-11 CONNECTOR, FPC (ZIF) 39P
CN702 1-817-707-11 CONNECTOR, FPC 14P
CN703 1-815-333-11 CONNECTOR, FPC (ZIF) 33P
CN704 1-778-592-21 CONNECTOR, BOARD TO BOARD 50P
< DIODE >
D001 8-719-056-23 DIODE MA2S111-(K8).SO
D002 8-719-056-23 DIODE MA2S111-(K8).SO
D003 8-719-158-49 DIODE RD12SB2
D004 8-719-056-23 DIODE MA2S111-(K8).SO
D005 8-719-069-29 DIODE RB520S-30TE61
D006 8-719-069-29 DIODE RB520S-30TE61
D007 8-719-069-29 DIODE RB520S-30TE61
D008 8-719-069-29 DIODE RB520S-30TE61
D009 8-719-069-29 DIODE RB520S-30TE61
D010 8-719-069-29 DIODE RB520S-30TE61
D012 8-719-069-29 DIODE RB520S-30TE61
D015 8-719-056-23 DIODE MA2S111-(K8).SO
D101 8-719-056-23 DIODE MA2S111-(K8).SO
< FUSE >
0F001 1-576-416-21 FUSE (2A/36V)
0F002 1-576-603-21 FUSE (3.15A/24V)
0F003 1-576-416-21 FUSE (2A/36V)
0F004 1-576-570-21 FUSE, MICRO (1608 TYPE) (0.63A/32V)
SY-102
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
