Ref. No. Part No. Description Ref. No. Part No. Description
DSC-W1/W12
0 F005 1-576-570-21 FUSE, MICRO (1608 TYPE) (0.63A/32V)
< FERRITE BEAD >
FB101 1-469-876-11 INDUCTOR, FERRITE BEAD
FB102 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB103 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB105 1-414-228-11 INDUCTOR, FERRITE BEAD
FB303 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB306 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB307 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB308 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB309 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB310 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB311 1-500-284-21 INDUCTOR, FERRITE BEAD
FB501 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB502 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB503 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB504 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB505 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB506 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB507 1-500-284-21 INDUCTOR, FERRITE BEAD
< IC >
IC001 6-706-006-01 IC CXA8133AGF
IC002 6-703-060-01 IC S-8425AABPA-TF-G
IC201 6-706-005-01 IC BD6756GLV-E2
IC301 A-1055-130-A KWF BOARD, COMPLETE
IC302 6-704-365-01 IC NJM2578KJ1 (TE3)
IC304 8-759-698-31 IC TC7WH74FK (TE85R)
IC401 6-804-467-01 IC MB89083LGA-G-109-ERE1
IC501 (Note) IC JSCIS001BF01GA-T6
IC502 6-702-277-01 IC R1141Q181B-TR-FA
< COIL >
L001 1-456-500-11 INDUCTOR 10uH
L002 1-469-757-21 INDUCTOR 10uH
L003 1-456-500-11 INDUCTOR 10uH
L004 1-456-499-11 INDUCTOR 4.7uH
L005 1-456-500-11 INDUCTOR 10uH
L006 1-456-499-11 INDUCTOR 4.7uH
L007 1-456-499-11 INDUCTOR 4.7uH
L011 1-456-501-11 INDUCTOR 33uH
L012 1-469-556-21 INDUCTOR 15uH
L013 1-456-500-11 INDUCTOR 10uH
L014 1-469-570-11 INDUCTOR 10uH
L015 1-469-846-11 INDUCTOR 47uH
L101 1-469-561-21 INDUCTOR 100uH
L102 1-469-559-21 INDUCTOR 47uH
L103 1-469-555-21 INDUCTOR 10uH
L104 1-469-555-21 INDUCTOR 10uH
L301 1-469-570-11 INDUCTOR 10uH
L502 1-469-570-11 INDUCTOR 10uH
L601 1-412-026-11 INDUCTOR 1uH
< TRANSISTOR >
0 Q001 8-729-056-45 TRANSISTOR CPH6311-TL-E
Q002 8-729-032-62 TRANSISTOR 2SJ347-TE85L
Q003 8-729-055-89 TRANSISTOR MCH3306-TL-E
Q007 8-729-055-87 TRANSISTOR MCH5801-TL-E
Q008 8-729-055-89 TRANSISTOR MCH3306-TL-E
Q009 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
0 Q010 6-550-844-01 TRANSISTOR FDW2508P/GNL
Q011 8-729-055-89 TRANSISTOR MCH3306-TL-E
Q105 6-550-119-01 TRANSISTOR DTC144EMT2L
Q106 6-550-509-01 TRANSISTOR RN2907FE (TPLR3)
Q107 6-550-508-01 TRANSISTOR RN1907FE (TPLR3)
Q201 8-729-054-51 TRANSISTOR UP04116008S0
Q205 8-729-054-50 TRANSISTOR UP04501008S0
Q401 6-550-283-01 TRANSISTOR UNR32A600LS0
Q402 6-550-119-01 TRANSISTOR DTC144EMT2L
Q501 6-550-119-01 TRANSISTOR DTC144EMT2L
Q502 6-550-119-01 TRANSISTOR DTC144EMT2L
Q503 6-550-119-01 TRANSISTOR DTC144EMT2L
0 Q602 6-550-528-01 TRANSISTOR UPA650TT-E1-A
0 Q603 6-550-119-01 TRANSISTOR DTC144EMT2L
0 Q604 8-729-053-57 TRANSISTOR RN1902FE (TPLR3)
Q701 8-729-050-91 TRANSISTOR UNRL21300AS0
Q702 8-729-427-72 TRANSISTOR XP4501
< RESISTOR >
R001 1-240-726-91 METAL CHIP 470K 5% 1/20W
R002 1-240-707-91 METAL CHIP 10K 5% 1/20W
R003 1-240-722-91 METAL CHIP 220K 5% 1/20W
R004 1-240-718-91 METAL CHIP 100K 5% 1/20W
R006 1-240-726-91 METAL CHIP 470K 5% 1/20W
R007 1-240-678-91 METAL CHIP 33 5% 1/20W
R009 1-218-965-11 RES-CHIP 10K 5% 1/16W
R010 1-240-691-91 METAL CHIP 470 5% 1/20W
R011 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R012 1-208-939-11 METAL CHIP 150K 0.5% 1/16W
R014 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R017 1-240-729-91 METAL CHIP 1M 5% 1/20W
R018 1-240-672-11 METAL CHIP 10 5% 1/20W
R019 1-240-729-91 METAL CHIP 1M 5% 1/20W
R020 1-240-707-91 METAL CHIP 10K 5% 1/20W
R029 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R030 1-218-945-11 RES-CHIP 220 5% 1/16W
R034 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R035 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R101 1-218-977-11 RES-CHIP 100K 5% 1/16W
R102 1-240-695-91 METAL CHIP 1K 5% 1/20W
R103 1-694-535-91 SHORT CHIP 0
R104 1-694-535-91 SHORT CHIP 0
R106 1-240-687-91 METAL CHIP 220 5% 1/20W
R107 1-218-945-11 RES-CHIP 220 5% 1/16W
R108 1-240-687-91 METAL CHIP 220 5% 1/20W
R109 1-218-990-11 SHORT CHIP 0
R110 1-218-933-11 RES-CHIP 22 5% 1/16W
R111 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R112 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R113 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R114 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R118 1-218-976-11 RES-CHIP 82K 5% 1/16W
R119 1-218-989-11 RES-CHIP 1M 5% 1/16W
R120 1-218-981-11 RES-CHIP 220K 5% 1/16W
SY-102
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(Note) Part number is not fixed yet.
It will be notified by Supplement of Service
Manual when it is fixed.
To Next Page
