A ON/OFF (Power) lamp
B Shutter button
C ON/OFF (Power) button
D Flash
E Lens
F Speaker
G Self-timer lamp/Smile Shutter
lamp
H LCD screen
I (Playback) button
J Control button
MENU on: v/V/b/B/z
MENU off: DISP/ / / /
Tracking focus
K MENU button
L / (In-Camera Guide/Delete)
button
M USB / A/V OUT jack
N Hook for wrist strap
O Mode switch: (Still image)/
(Sweep Panorama)/
(Movie)
P For shooting: W/T (Zoom)
button
For viewing: (Playback
zoom) button/ (Index) button
Q Battery/memory card cover
R Microphone
S Battery insertion slot
T Battery eject lever
U Memory card slot
V Access lamp
W Tripod receptacle
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
Identifying parts
