DSX-A410BT/A415BT
4
DESTINATION SETTING METHOD
When the MAIN board or system controller (IC501) is replaced,
the destination setting is necessary.
1. Destination Setting
Set destination according to the procedure below.
1-1. Setting the Destination Code
1. In the state of source off (the clock is displayed on the liquid
crystal display), enter the test mode by pressing the buttons in
order of the [
4] → [MIC 5] → [u 6] (press only the [u 6]
button for two seconds).
Clock display
Note 1: There is displayed “1:00 AM”, depending on the destination.
2. In the state in which the software main version is displayed on
the liquid crystal display (refer to the following fi gure), enter
the destination setting mode by pressing the buttons in order
of the [
> M] → [m .] → [PUSH ENTER/MENU/
VOICE].
(Displayed characters/values in the following fi gure are ex-
ample)
Software main version
3. Input the alphanumeric character of 6 digits displayed on the
liquid crystal display, and execute the destination setting.
Note 2: The displayed contents of the following fi gure is an example. The
destination code is different depending on the destination of the
product.
Note 3: Refer to the following “1-3. Entering the Destination Code” for
operation method.
Destination code
6 digits
4. The resetting operation is executed by pressing the [ OFF
SRC] button for 1 second after the setting ends, and the unit
returns to the normal condition.
Display after reset
Note 4: There is displayed “1:00 AM”, depending on the destination.
1-2. Display in Destination Setting Mode
Note: The displayed contents of the following fi gure is an example. The
destination code is different depending on the destination of the
product.
Destination code
OP0OP1OP2OP3OP4OP5
6 digits
1-3. Entering the Destination Code
• Method of operation by main unit
1. Rotate the control dial, and select the alphanumeric character
of “0 to F”.
2. The digit advances by pressing the [PUSH ENTER/MENU/
VOICE] or [> M] button.
The digit returns by pressing the [ MODE] or [m .] but-
ton.
3. The setting is completed by pressing the [PUSH ENTER/
MENU/ VOICE] button at the state of cursor position of
“OP0”, then the display turns off, the initialization operation
is done, and the display returns to the clock display.
• Method of operation by remote commander
(DSX-A410BT: E, AR, IND, AUS/DSX-A415BT)
Note: The model to which the remote commander is not attached can
also be operated by using the optional remote commander.
1. Press the [
V
] or [
v
] button, and select the alphanumeric char-
acter of “0 to F”.
2. The digit advances by pressing the [
b
] or [ENTER] button.
The digit returns by pressing the [
B
] button.
3. The setting is completed by pressing the [ENTER] button at
the state of cursor position of “OP0”, then the display turns off,
the initialization operation is done, and the display returns to
the clock display.
Ver. 1.1
