SERVICE MANUAL
Sony CONFIDENTIAL
For Authorized Servicer
DSX-GS80/M80
SPECIFICATIONS
DSX-GS80: US, CND
FM/AM Bluetooth
®
CAR AUDIO
DSX-GS80: AEP, UK
FM/AM/LW Bluetooth
®
CAR AUDIO
DSX-M80
FM/AM Bluetooth
®
MARINE AUDIO
US Model
Canadian Model
AEP Model
UK Model
DSX-GS80/M80
E Model
DSX-M80
Ver. 1.0 2019.10
• This model is not equipped with a mechanism deck.
Photo: DSX-GS80
FOR THE CUSTOMERS IN THE USA. NOT
(DSX-GS80: US, CND/DSX-M80)
APPLICABLE IN CANADA, INCLUDING IN
THE PROVINCE OF QUEBEC.
POUR LES CLIENTS AUX ÉTATS-UNIS.
NO
N APPLICABLE AU CANADA, Y
COMPRIS LA PROVINCE DE QUÉBEC.
AUDIO POWER SPECIFICATIONS
CTA2006 Standard
Power Output: 45 Watts RMS × 4
at 4 Ohms < 1% THD+N
SN Ratio: 80 dBA 
(reference: 1 Watt into 4 Ohms)
Radio section
(DSX-GS80: US, CND)
(DSX-GS80: AEP, UK)
(DSX-M80)
FM
Tuning range: 87.5 MHz – 107.9 MHz
Usable sensitivity: 8 dBf
Signal-to-noise ratio: 73 dB
Separation: 50 dB at 1 kHz
AM
Tuning range: 530 kHz – 1,710 kHz
Sensitivity: 26 µV
USB Player section
Interface:
USB1 port (front): USB (Hi-speed)
USB2 port (rear): USB (Hi-speed)
Maximum current:
USB1 port (front): 1 A
USB2 port (rear): 1.5 A
The maximum number of recognizable files
(
tracks): 10,000
Compatible Android Open Accessory
protocol (AOA): 2.0
Corresponding codec:
MP3 (.mp3)
Bit rate: 8 kbps – 320 kbps (Supports VBR
(Variable Bit Rate))
Sampling rate: 16 kHz – 48 kHz
WMA (.wma)
Bit rate: 32 kbps – 192 kbps (Supports VBR
(V
a
riable Bit Rate))
Sampling rate: 32 kHz, 44.1 kHz, 
48 kHz
AAC (.m4a, .mp4)
Bit rate: 8 kbps – 320 kbps
Sampling rate: 11.025 kHz – 48 kHz
WAV (.wav)
Bit depth: 16 bit
Sampling rate: 44.1 kHz, 48 kHz
FLAC (.flac)
Bit depth: 16 bit, 24 bit
Sampling rate: 44.1 kHz, 48 kHz
Supported file system: FAT16, FAT32
Wireless Communication
Communication System:
BLUETOOTH Standard version 3.0
Output:
BLUETOOTH Standard Power Class 2 
(Max. Conducted +1 dBm)
Maximum communication range*
1
:
Line of sight approx. 10 m (33 ft)
Frequency band:
2.4 GHz band (2.4000 GHz – 2.4835 GHz)
Modulation method: FHSS
Compatible BLUETOOTH Profiles*
2
:
A2DP (Advanced Audio Distribution Profile)
1.3
AVRCP (Audio Video Remote Control
Profile) 1.5
HFP (Handsfree Profile) 1.6
PBAP (Phone Book Access Profile)
SPP (Serial Port Profile)
Corresponding codec:
SBC (.sbc), AAC (.m4a)
*1 The actual range will vary depending on factors
such as obstacles between devices, magnetic
fields around a microwave oven, static electricity,
reception sensitivity, antenna (aerial)’s
performance, operating system, software
application, etc.
*2 BLUETOOTH standard profiles indicate the
purpose of BLUETOOTH communication between
devices.
Power amplifier section
Output: Speaker outputs
Speaker impedance: 2 /4  – 8 
Maximum power output: 100 W × 4 (at 2 /
4 )
FM
Tuning range:
When [AREA] is set to [EUROPE]:
87.5 MHz – 108.0 MHz
When [AREA] is set to [RUSSIA]:
FM1/FM2: 87.5 MHz – 108.0 MHz
(at 50 kHz step)
FM3: 65 MHz – 74 MHz (at 30 kHz step)
Usable sensitivity: 8 dBf
Signal-to-noise ratio: 73 dB
Separation: 50 dB at 1 kHz
AM/LW
Tuning range:
531 kHz – 1,602 kHz (AM),
153 kHz – 279 kHz (LW)
Sensitivity:
AM: 26 V,
LW: 50 V
FM
Tuning range:
87.5 MHz – 108.0 MHz (at 50 kHz step)
87.5 MHz – 108.0 MHz (at 100 kHz step)
87.5 MHz – 107.9 MHz (at 200 kHz step)
FM tuning step:
50 kHz/100 kHz/200 kHz switchable
Usable sensitivity: 8 dBf
Signal-to-noise ratio: 73 dB
Separation: 50 dB at 1 kHz
AM
Tuning range:
531 kHz – 1,602 kHz (at 9 kHz step)
530 kHz – 1,710 kHz (at 10 kHz step)
AM tuning step:
9 kHz/10 kHz switchable
Sensitivity: 26 µV
General
(DSX-GS80)
Power requirements: 12 V DC car battery
(negative ground (earth))
(DSX-M80)
Power requirements: 12 V DC boat battery
(negative ground (earth))
Rated current consumption: 10 A
Rated current consumption: 10 A
Dimensions:
Approx. 178 mm × 50 mm × 177 mm 
(7
1
/8 in × 2 in × 7 in) (w/h/d)
Mounting dimensions:
Approx. 182 mm × 53 mm × 160 mm 
(7
RM-X231 (DSX-GS80: US, CND)
RM-X232 (DSX-M80)
1
/4 in × 2
1
/8 in × 6
3
/8 in) (w/h/d)
Mass: Approx. 1.0 kg (2 lb 4 oz)
Package contents:
Main unit (1)
Remote commander (1):
Parts for installation and connections 
(1 set)
Design and specifications are subject to
c
hange without notice.
