DXC-990/990P, DXC-390/390P Sales Manual
–
45
13. Q&A
Note) The output signals from CMA-D3/D3CE are selectable from the RGB output or Y/C output.
Q.10: When using the CMA-D3/D3CE camera adaptor with a CCZ-A
cable, does the user have to purchase a separate CCZZ-1E
connection adaptor?
A: No.
The CCZZ-1E connector adaptor is supplied with the CCMC-3MZ cable.
The user does not have to purchase another CCZZ-1E.
Q.11: Does the cable length effect the DC power supply when
using the CMA-D3/D3CE?
A: For DC operation, the usable cable length is limited by the supplied voltage. If you use a
camera cable of 50 m or longer, you need to connect a 11.5 to 15 V DC power supply.
Q.12: What are the differences among power supply units?
A: The following is a comparison table between CMA-D3/D3CE and CMA-D2 Series
CMA-D2 Series with CMA-D2 Series with
CMA-D3/D3CE
CCMC-12P** CCDC-**
Cable Distance Up to 25 m Up to 100 m Up to 100 m
VBS output Yes No Yes
RGB output No No Yes
Y/C output Yes No Yes
VBS Genlock Yes No Yes
HD, VD input or output No No Yes
Trig in/WEN output No No Yes
Control by RM-C950 No No Yes
AC IN Yes Yes Yes
DC IN No No Yes
