Sony ECM-M1 User Manual

Help Guide
Shotgun Microphone
ECM-M1
Attaching/removing to/from the camera
Attach the shotgun microphone to a camera.
Note
Before attaching/removing this unit to/from a camera, turn off the power to the camera.
Remove the connector protect cap from this unit.
1
Release the lock by rotating the lock dial (
) and attach this unit to a camera ( ).
Before attaching this unit to a camera, rotate the lock dial counterclockwise until it stops and make sure that the
lock is released.
2
Rotate the lock dial in the LOCK direction to firmly secure the unit.
3
6

Sony ECM-M1 Specifications

General

Type	Digital camera microphone
Sensitivity (1kHz)	0.1 mV/Pa
Microphone frequency	40 - 20000 Hz
Microphone sensitivity	-20 dB
Connectivity technology	-
Product color	Black
Operating voltage	7.2 V
Number of products included	1 pc(s)

Weight and Dimensions

Depth	64.4 mm
Width	40 mm
Height	72.2 mm
Microphone weight	65 g
