Inquiry Command List (3/4)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_LR_ReverseModeInq 8x 09 04 61 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_FreezeModeInq 8x 09 04 62 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 00 FF Off
y0 50 04 FF Black & White
CAM_PictureFlipModeInq 8x 09 04 66 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_ICRModeInq 8x 09 04 01 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AutoICRModeInq 8x 09 04 51 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AutoICRThresholdInq 8x 09 04 21 FF y0 50 00 00 0p 0q FF
pq: ICR On  Off Threshold Level
CAM_AutoICRAlarmReplyInq 8x 09 04 31 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AutoICRAlarmReply (Reply) y0 07 04 31 0p FF
p: 2=Off  On, 3=On  Off
CAM_MemoryInq 8x 09 04 3F FF y0 50 pp FF pp: Memory number recalled last
CAM_MemSaveInq 8x 09 04 23 0X FF y0 50 0p 0q 0r 0s FF X: 00h to 07h (Address)
pqrs: 0000h to FFFFh (Data)
CAM_DisplayModeInq 8x 09 04 15 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_MuteModeInq 8x 09 04 75 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_SetMaskTableInq 8x 09 05 70 FF y0 50 0m FF m: Table
CAM_PrivacyDisplayInq 8x 09 04 77 FF y0 50 pp pp pp pp FF pp pp pp pp: Mask Display (0: Off, 1: On)
CAM_PrivacyPanTiltInq 8x 09 04 79 FF y0 50 0p 0p 0p 0q 0q 0q FF ppp: Pan
qqq: Tilt
CAM_PrivacyPTZInq 8x 09 04 7B mm FF y0 50 0p 0p 0p 0q 0q 0q 0r 0r 0r 0r
FF
mm: Mask Settings
ppp: Pan
qqq: Tilt
rrrr: Zoom
CAM_PrivacyMonitorInq 8x 09 04 6F FF y0 50 pp pp pp pp FF pp pp pp pp: Mask is displayed now.
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID
CAM_VersionInq 8x 09 00 02 FF y0 50 00 20
mn pq rs tu vw FF
mnpq: Model Code (07xx)
rstu: ROM version
vw: Socket Number (=02)
CAM_ContinuousZoomPos
ReplyModeInq
8x 09 04 69 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_ZoomPosReply
IntervalTimeInq
8x 09 04 6A FF y0 50 00 00 0p 0p FF pp: Interval Time
CAM_Continuous
FocusPosReplyModeInq
8x 09 04 16 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_ExAutoICROnLevelInq 8x 09 04 1F 21 01 FF y0 50 00 00 0p 0q FF pq:Auto ICR Off/On threshold at ICR
pq=00h to 1Ch
CAM_MinShutterInq 8x 09 04 12 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_MinShutterLimitInq 8x 09 04 13 FF y0 50 00 00 0p 0q FF pq: MinShutter Position
CAM_HLCInq 8x 09 04 14 FF y0 50 0p 0q FF p: HLC level (0: OFF, 1: low, 2: mid, 3: high)
q: HLC mask level (0: OFF, 1 to F: level low to high)
CAM_RegisterValueInq 8x 09 04 24 pp FF y0 50 0q 0q FF pp: Register No.
CAM_ContinuousZoomPos
ReplyModeInq
8x 09 04 69 FF y0 50 0p FF p: 2=On, 3=Off
