Sony FD Trinitron KV-32LS35E - A Board Variant Parts; A Board Variant Parts (KV-28 LS35); VM Board Parts (KV-32 LS35)

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
59
R053 1-216-095-91 RES-CHIP 82K 5.00% 1/10W
R455 1-412-002-41 INDUCTOR 4.7UH
R517 1-215-453-91 METAL 22K 1% 1/4W
R518 1-216-069-91 RES-CHIP 6.8K 5% 1/10W
R534 1-216-111-91 RES-CHIP 390K 5% 1/10W
R535 1-216-105-91 RES-CHIP 220K 5% 1/10W
R544 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R546 1-215-917-91 METAL OXIDE 1K 5% 3W
R568 1-216-480-91 METAL OXIDE 820 5% 3W
R583 1-216-077-91 RES-CHIP 15K 5% 1/10W
R600 1-216-629-91 RES-CHIP 120 0.50% 1/10W
R601 1-216-647-91 RES-CHIP 680 0.50% 1/10W
< TRANSFORMER >
T511 £ 1-453-308-31 TRANSFORMER ASSY, FLYBACK (NX4521//Z2B4)
T533 1-429-306-11 TRANSFORMER, HORIZONTAL LINEAR
< TUNER >
TU101 1-693-555-11 TUNER STEREO (KV-32LS35B)
1-693-556-11 TUNER STEREO (KV-32LS35E)
1-693-557-11 TUNER STEREO (KV-32LS35U)
*A-1638-156-A C Board, Complete
*1-681-784-11 PWB, C
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C701 1-136-189-00 MYLAR 0.1UF 10.00% 250V
C702 1-126-964-11 ELECT 10UF 20.00% 50V
C703 1-101-004-00 CERAMIC 0.01UF 50V
C704 1-107-649-11 ELECT 2.2UF 20.00% 250V
C705 1-162-318-11 CERAMIC 0.001UF 10.00% 500V
C706 1-162-318-11 CERAMIC 0.001UF 10.00% 500V
C708 1-162-114-00 CERAMIC 0.0047UF 2KV
C710 1-107-652-11 ELECT 10UF 20.00% 250V
C1803 1-101-005-00 CERAMIC 0.022UF 50V
C1804 1-126-964-11 ELECT 10UF 20.00% 50V
C1805 1-101-880-00 CERAMIC 47PF 5.00% 50V
< CONNECTOR >
CN702 1-695-915-11 TAB (CONTACT)
CN703 *1-564-510-11 PLUG, CONNECTOR 7P
CN706 1-695-915-11 TAB (CONTACT)
CN707 *1-564-508-11 PLUG, CONNECTOR 5P
CN1801 *1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-901-83 DIODE 1SS83
< CRYSTAL >
X001 1-578-774-71 VIBRATOR, CRYSTAL
X201 1-760-628-11 VIBRATOR, CRYSTAL
A Board Variant Parts KV-28LS35
< CAPACITOR >
C522 1-137-447-11 MYLAR 0.27UF 5.00% 50V
C536 1-115-521-11 FILM 0.82UF 5.00% 250V
C542 1-162-115-51 CERAMIC 330PF 10.00% 2KV
C555 1-117-652-11 FILM 22000PF 3.00% 1.2KV
< RESISTOR >
JR421 1-216-295-91 SHORT 0
R053 1-216-077-91 RES-CHIP 15K 5% 1/10W
R455 1-216-295-91 SHORT 0
R513 1-216-105-91 RES-CHIP 220K 5% 1/10W
R517 1-215-449-91 METAL 15K 1% 1/4W
R521 1-216-105-91 RES-CHIP 220K 5% 1/10W
R534 1-216-097-91 RES-CHIP 100K 5% 1/10W
R535 1-216-097-91 RES-CHIP 100K 5% 1/10W
R546 1-216-480-11 METAL OXIDE 820 5% 3W
R568 1-215-916-00 METAL OXIDE 680 5% 3W
R583 1-216-081-91 RES-CHIP 22K 5% 1/10W
R600 1-216-641-11 METAL CHIP 390 0.5% 1/10W
R601 1-216-643-11 METAL CHIP 470 0.5% 1/10W
< TRANSFORMER >
T511 £ 1-453-308-41 TRANSFORMER ASSY, FLYBACK (NX4521//Z2B4)
T533 1-433-980-12 TRANSFORMER, HORIZONTAL LINEAR
< TUNER >
TU101 8-598-535-00 FRONTEND BTF-EF411 (KV-28LS35B)
8-598-533-00 FRONTEND BTF-EC411 (KV-28LS35E)
8-598-529-00 FRONTEND BTF-EU611 (KV-28LS35U)
A Board Variant Parts KV-32LS35
< CAPACITOR >
C536 1-115-522-21 FILM 1UF 5.00% 250V
C540 1-137-051-91 FILM 0.033UF 10.00% 400V
C542 1-161-754-61 CERAMIC 0.001UF 10.00% 2KV
C555 1-127-717-11 FILM 19000PF 3.00% 1.2KV
C619 1-164-644-51 CERAMIC 330PF 10.00% 500V
C621 1-164-644-51 CERAMIC 330PF 10.00% 500V
< RESISTOR >
JR101 1-216-295-91 SHORT 0
A C
