9
GB
GTK-XB7.4-582-492-21(1)
(power) button
Press to turn on or off the system.
(power) indicator
— Lights up in green while the
system is turned on.
— Lights up in amber while the
system is turned off, and when
the BLUETOOTH standby mode is
turned on.
FUNCTION
PAIRING button
— Press repeatedly to select the
BLUETOOTH, USB, or Audio In
function.
— When the BLUETOOTH function
is selected, hold down to
activate BLUETOOTH pairing.
— Press to stop the built-in sound
demonstration.
EXTRA BASS button
— Press to generate more dynamic
sound (page21).
— When you hold down this button
for more than 2 seconds, the
built-in sound demonstration
will be played back.
EXTRA BASS inidicator
(page21)
(BLUETOOTH) indicator
(page15)
USB indicator (page14)
AUDIO IN indicator (page27)
(N-Mark) (page17)
Volume –/+* buttons
Press to adjust the volume.
Remote control sensor
(USB) port
Use to connect a USB device.
SPEAKER ADD button (page25)
SPEAKER ADD L/R indicators
(page25)
PARTY CHAIN button (page24)
PARTY CHAIN indicator
(page24)
Audio output and input jacks
Use an audio cord (not supplied)
to make either connection as
follows:
• AUDIO/PARTY CHAIN OUT L/R
jacks
— Connect to the audio
input jacks of an optional
equipment.
— Connect to another audio
system to enjoy the Party
Chain function (page22).
• AUDIO/PARTY CHAIN IN L/R
jacks
— Connect to the audio output
jacks of a TV or an audio/
video equipment. The sound is
output through this system.
— Connect to another audio
system to enjoy the Party
Chain function (page22).
AC IN jack (page11)
* The volume + button on the unit has
a tactile dot. Use the tactile dot as a
reference when operating the system.
