93
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
I/O LOADING
R648 1-216-843-11 METAL CHIP 68K 5% 1/16W
(S500:AEP,CIS,UK/S800)
R649 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT S500:AEP,UK)
R650 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT S500:AEP,UK)
R700 1-216-021-00 METAL CHIP 68 5% 1/10W
(S500:AEP,UK)
R700 1-218-289-11 RES-CHIP 510 5% 1/16W
(EXCEPT S500:AEP,UK)
R701 1-216-021-00 METAL CHIP 68 5% 1/10W
(S500:AEP,UK)
R701 1-218-289-11 RES-CHIP 510 5% 1/16W
(EXCEPT S500:AEP,UK)
R702 1-216-021-00 METAL CHIP 68 5% 1/10W
(S500:AEP,UK)
R702 1-218-289-11 RES-CHIP 510 5% 1/16W
(EXCEPT S500:AEP,UK)
R703 1-216-022-00 METAL CHIP 75 5% 1/10W
(S500:AEP,UK,KR)
R703 1-218-285-11 RES-CHIP 75 5% 1/16W
(EXCEPT S500:AEP,UK)
R704 1-216-022-00 METAL CHIP 75 5% 1/10W
(S500:AEP,UK)
R704 1-218-285-11 RES-CHIP 75 5% 1/16W
(EXCEPT S500:AEP,UK)
R705 1-216-022-00 METAL CHIP 75 5% 1/10W
(S500:AEP,UK)
R705 1-218-285-11 RES-CHIP 75 5% 1/16W
(EXCEPT S500:AEP,UK)
R706 1-216-022-00 METAL CHIP 75 5% 1/10W
(S500:AEP,UK)
R706 1-218-285-11 RES-CHIP 75 5% 1/16W
(EXCEPT S500:AEP,UK)
R707 1-216-022-00 METAL CHIP 75 5% 1/10W
(S500:AEP,UK)
R707 1-218-285-11 RES-CHIP 75 5% 1/16W
(EXCEPT S500:AEP,UK)
R708 1-216-025-11 RES-CHIP 100 5% 1/10W
(S500:AEP,UK)
R708 1-216-809-11 METAL CHIP 100 5% 1/16W
(EXCEPT S500:AEP,UK)
R709 1-216-022-00 METAL CHIP 75 5% 1/10W
(S500:AEP,UK)
R709 1-218-285-11 RES-CHIP 75 5% 1/16W
(EXCEPT S500:AEP,UK)
R711 1-216-081-00 METAL CHIP 22K 5% 1/10W
(S500:AEP,UK)
R711 1-216-837-11 METAL CHIP 22K 5% 1/16W
(EXCEPT S500:AEP,UK)
R712 1-216-049-11 RES-CHIP 1K 5% 1/10W
(S500:AEP,UK)
R712 1-216-821-11 METAL CHIP 1K 5% 1/16W
(EXCEPT S500:AEP,UK)
R713 1-216-081-00 METAL CHIP 22K 5% 1/10W
(S500:AEP,UK)
R713 1-216-837-11 METAL CHIP 22K 5% 1/16W
(EXCEPT S500:AEP,UK)
R714 1-216-073-91 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R714 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R716 1-216-037-00 METAL CHIP 330 5% 1/10W
(S500:AEP,UK)
R716 1-216-815-11 METAL CHIP 330 5% 1/16W
(EXCEPT S500:AEP,UK)
R717 1-216-073-91 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R717 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R718 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R718 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R719 1-216-041-00 METAL CHIP 470 5% 1/10W
(S500:AEP,UK)
R719 1-216-817-11 METAL CHIP 470 5% 1/16W
(EXCEPT S500:AEP,UK)
R720 1-216-041-00 METAL CHIP 470 5% 1/10W
(S500:AEP,UK)
R720 1-216-817-11 METAL CHIP 470 5% 1/16W
(EXCEPT S500:AEP,UK)
R721 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R721 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R722 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R722 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R723 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R723 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
< VIBRATOR >
X601 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
(S500:AEP,CIS,UK/S800)
************************************************************
1-676-599-11 LOADING BOARD
**************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER SLIDE
************************************************************
