94
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER
A-4726-412-A POWER BOARD, COMPLETE (S500:US)
***********************
A-4726-413-A POWER BOARD, COMPLETE (S500:CND)
***********************
A-4726-597-A POWER BOARD, COMPLETE (S500:MX)
***********************
A-4726-829-A POWER BOARD, COMPLETE (S500:AEP,CIS,UK)
***********************
A-4726-892-A POWER BOARD, COMPLETE (S500:TW)
***********************
A-4726-899-A POWER BOARD, COMPLETE
(S500:AUS/S800:AUS)
***********************
A-4726-900-A POWER BOARD, COMPLETE (S500:E32,EA)
***********************
A-4726-909-A POWER BOARD, COMPLETE
(S500:E12,MY,SP,HK,AR)
***********************
A-4726-593-A POWER BOARD, COMPLETE (S800:AEP,CIS,UK)
***********************
A-4727-401-A POWER BOARD, COMPLETE (S800:EA)
***********************
A-4727-404-A POWER BOARD, COMPLETE (S800:HK)
***********************
A-4727-410-A POWER BOARD, COMPLETE (S800:TW)
***********************
A-4727-602-A POWER BOARD, COMPLETE (S500:KR/S800:KR)
***********************
A-4727-604-A POWER BOARD, COMPLETE (S800:MX)
***********************
7-685-548-01 SCREW +BTP 3X12 TYPE1
7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
< CAPACITOR >
0 C901 1-117-703-11 CERAMIC 0.0047uF 99% 250V
0 C902 1-115-165-11 FILM 0.1uF 20.00% 275V
0 C903 1-162-290-31 CERAMIC 470PF 10% 50V
0 C904 1-115-165-11 FILM 0.1uF 20.00% 275V
(AEP,CIS,UK,KR)
0 C904 1-104-705-11 MYLAR 0.1uF 20.00% 250V
(US,CND,MX)
0 C904 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(E12,E32,EA,MY,SP,HK,AR,AUS)
0 C905 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US,CND,MX)
0 C905 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US,CND,MX)
0 C906 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(S500:US,CND,MX)
0 C906 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US,CND,MX)
0 C907 1-164-159-21 CERAMIC 0.1uF 50V
0 C908 1-115-165-11 FILM 0.1uF 20.00% 275V
(AEP,CIS,UK,KR,HK,AUS)
0 C908 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US,CND,MX)
0 C908 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(E12,E32,EA,MY,SP,TW,AR)
0 C909 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
0 C910 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
0 C911 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
0 C912 1-137-994-11 ELECT 820uF 20% 200V
(US,CND,MX)
0 C913 1-113-481-11 FILM 1000PF 5.00% 630V
(E12,E32,EA,MY,SP,HK,AR)
0 C913 1-136-203-11 FILM 10000PF 5.00% 630V
(US,CND,TW,MX,AUS)
0 C913 1-164-143-11 CERAMIC 0.001uF 10.00% 1KV
(AEP,CIS,UK,KR)
0 C914 1-126-967-11 ELECT 47uF 20.00% 50V
0 C915 1-162-290-31 CERAMIC 470PF 10% 50V
(E12,E32,EA,MY,SP,HK,AR)
0 C915 1-162-292-31 CERAMIC 680PF 10% 50V
(AEP,CIS,UK,KR)
0 C915 1-162-286-21 CERAMIC 220PF 10.00% 50V
(US,CND,TW,MX,AUS)
0 C916 1-125-772-51 CERAMIC 1500PF 10.00% 2KV
(AEP,CIS,UK,KR)
0 C916 1-117-454-11 FILM 4700PF 5.00% 630V
(US,CND,MX)
0 C916 1-137-751-21 FILM 2200PF 3% 800V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
C917 1-113-907-51 CERAMIC 0.0022uF 99% 250V
C918 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C919 1-115-789-11 ELECT 1000uF 20.00% 25V
C920 1-136-203-11 FILM 10000PF 5.00% 630V
(US,CND,TW,MX,AUS)
C920 1-117-454-11 FILM 4700PF 5.00% 630V
(AEP,UK,CIS,E12,E32,EA,MY,SP,HK,KR,AR)
C921 1-115-819-11 ELECT 2200uF 20.00% 35V
(US,CND,MX)
C921 1-110-602-51 ELECT 1800uF 20.00% 25V
(AEP,CIS,UK,KR)
C921 1-110-617-51 ELECT 2200uF 20.00% 50V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
C922 1-128-560-11 ELECT 22uF 20.00% 100V
(US,CND,MX)
C922 1-126-965-11 ELECT 22uF 20.00% 50V
(EXCEPT US,CND,MX)
C923 1-115-819-11 ELECT 2200uF 20.00% 35V
(US,CND,MX)
C923 1-110-602-51 ELECT 1800uF 20.00% 25V
(AEP,CIS,UK,KR)
C923 1-110-617-51 ELECT 2200uF 20.00% 50V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
C924 1-126-953-11 ELECT 2200uF 20.00% 35V
(US,CND,AEP,UK,KR,MX)
C924 1-126-972-11 ELECT 1000uF 20.00% 50V
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
C925 1-126-960-11 ELECT 1uF 20.00% 50V
C926 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C927 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C928 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C929 1-104-665-11 ELECT 100uF 20.00% 10V
C930 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C931 1-126-916-11 ELECT 1000uF 20.00% 6.3V
To Next Page
