95
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER
C932 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C933 1-126-768-11 ELECT 2200uF 20.00% 16V
(US,CND,MX)
C933 1-126-942-61 ELECT 1000uF 20.00% 16V
(EXCEPT US,CND,MX)
C936 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-564-321-21 PIN, CONNECTOR 2P
(US,CND,AEP,CIS,UK,KR,MX)
CN902 1-564-321-00 PIN, CONNECTOR 2P
(EXCEPT US,CND,AEP,CIS,UK,KR,MX)
* CN904 1-564-778-11 PLUG, CONNECTOR (2.5MM) 4P
* CN905 1-568-939-11 PIN, CONNECTOR 12P
< DIODE >
0 D901 8-719-911-19 DIODE 1SS133T-72 (AEP,CIS,UK,KR)
0 D901 8-719-991-33 DIODE 1SS133T-77 (EXCEPT AEP,CIS,UK,KR)
0 D902 8-719-022-92 DIODE RBV-604 (US,CND,TW,MX,AUS)
0 D902 8-719-312-05 DIODE RBV-606 (AEP,CIS,UK,KR)
0 D902 8-719-510-53 DIODE RBV-406H-01
(E12,E32,EA,HK,MY,SP,AR)
0 D903 8-719-010-98 DIODE MTZJ-T-77-22A (US,CND,MX)
0 D903 8-719-922-03 DIODE MTZJ-T-77-18C (EXCEPT US,CND,MX)
0 D904 8-719-110-61 DIODE MTZJ-T-77-24A
0 D905 8-719-200-91 DIODE 11EQS10-TA1
0 D906 8-719-200-91 DIODE 11EQS10-TA1
0 D907 8-719-200-91 DIODE 11EQS10-TA1
0 D908 8-719-080-26 DIODE SARS01V0
D909 8-719-079-46 DIODE FMB-G14L
D910 8-719-200-91 DIODE 11EQS10-TA1
D911 8-719-313-14 DIODE FML-22S (US,CND,AEP,UK,KR,MX)
D912 8-719-110-42 DIODE MTZJ-T-77-15C
D913 8-719-404-50 DIODE MA111-TX
D914 8-719-210-21 DIODE 11EQS04-TA1B
D915 8-719-404-50 DIODE MA111-TX
D916 8-719-210-21 DIODE 11EQS04-TA1B
D917 8-719-200-82 DIODE 11ES2-NTA1B
D918 8-719-404-50 DIODE MA111-TX
D920 1-216-296-11 SHORT 0 (US,CND,MX)
D921 1-216-296-11 SHORT 0 (US,CND,MX)
< EARTH >
0 EB901 1-537-770-21 TERMINAL BOARD, GROUND
0 EB902 1-537-770-21 TERMINAL BOARD, GROUND
0 EB903 1-537-770-21 TERMINAL BOARD, GROUND (MX)
< FERRITE BEAD >
0 FB901 1-412-473-21 INDUCTOR 0uH
< FUSE >
0 F901 1-533-420-11 FUSE, GLASS CYLINDRICAL(DIA.5) 5A/125V
(US,CND,MX)
0 F901 1-533-471-11 FUSE, GLASS TUBE (DIA. 5T) 3.15A/250V
(EXCEPT US,CND,MX)
< FUSE HOLDER >
FH901 1-533-313-11 HOLDER, FUSE
FH902 1-533-313-11 HOLDER, FUSE
< IC >
0IC901 8-749-017-79 IC STR-F6676 (AEP,CIS,UK,KR)
0IC901 6-700-162-01 IC STR-F6426S (US,CND,MX)
IC902 6-700-388-01 IC SE-B2
IC903 6-700-812-01 IC SI-8050JF
IC904 8-759-332-29 IC M51945BL
IC905 8-759-450-47 IC BA05T
IC906 6-700-813-01 IC SI-8033JF
IC907 8-759-390-72 IC TC4S584F(TE85R)
(US,CND,AEP,CIS,UK,KR,MX)
IC907 8-759-257-96 IC TC7S14FU(TE85R)
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
< COIL >
L901 1-424-860-11 INDUCTOR 10uH
(US,CND,AEP,CIS,UK,KR,MX)
L901 1-419-505-11 INDUCTOR 10uH
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
L902 1-419-506-11 INDUCTOR 150uH (AEP,CIS,UK,KR)
L902 1-419-253-11 INDUCTOR 100uH
(US,CND,E12,E32,EA,MY,SP,HK,TW,MX,AR,AUS)
L903 1-419-506-11 INDUCTOR 150uH (AEP,CIS,UK,KR)
L903 1-419-253-11 INDUCTOR 100uH
(US,CND,E12,E32,EA,MY,SP,HK,TW,MX,AR,AUS)
L904 1-414-398-11 INDUCTOR 10uH
L905 1-414-398-11 INDUCTOR 10uH
L906 1-414-398-11 INDUCTOR 10uH
L907 1-414-398-11 INDUCTOR 10uH
L908 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-424-930-11 COIL, LINE FILTER (US,CND,MX)
< TRANSISTOR >
0 Q901 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
0 Q902 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
0 Q903 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q905 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q906 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q907 8-729-030-19 TRANSISTOR 2SB1640(TP)
(US,CND,AEP,CIS,UK,KR,MX)
Q907 8-729-209-60 TRANSISTOR 2SB1375
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
Q908 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q909 8-729-027-49 TRANSISTOR DTC123EKA-T146
Q910 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q911 8-729-900-53 TRANSISTOR DTC114EKA-T146
(US,CND,MX)
Q915 8-729-027-23 TRANSISTOR DTA114EKA-T146 (TW,AUS)
Q915 8-729-900-53 TRANSISTOR DTC114EKA-T146
(EXCEPT TW,AUS)
Ver 1.2 2002.05
HCD-S500/S800
