96
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER
Q910 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q911 8-729-900-53 TRANSISTOR DTC114EKA-T146
(US,CND,MX)
Q915 8-729-027-23 TRANSISTOR DTA114EKA-T146 (TW,AUS)
Q915 8-729-900-53 TRANSISTOR DTC114EKA-T146
(EXCEPT TW,AUS)
< PHOTO COUPLER >
0 PC901 8-749-019-04 PHOTO COUPLER TLP421
0 PC902 8-749-019-04 PHOTO COUPLER TLP421
< RESISTOR >
0 R900 1-219-237-11 SOLID 3.3M 20% 1/2W
(US,CND,MX)
0 R900 1-202-725-00 SOLID 3.3M 10% 1/2W
(TW,AUS)
0 R901 1-249-415-11 CARBON 680 5% 1/4W F
0 R902 1-216-361-31 METAL OXIDE 0.22 5% 2W
(AEP,CIS,UK)
0 R902 1-243-979-31 METAL OXIDE 0.1 5% 2W
(US,CND,MX)
0 R903 1-216-361-31 METAL OXIDE 0.22 5% 2W
(AEP,CIS,UK)
0 R903 1-243-979-31 METAL OXIDE 0.1 5% 2W
(US,CND,MX)
0 R904 1-247-881-00 CARBON 120K 5% 1/4W
0 R905 1-249-439-11 CARBON 68K 5% 1/4W
0 R906 1-249-424-11 CARBON 3.9K 5% 1/4W F
0 R907 1-249-425-11 CARBON 4.7K 5% 1/4W F
0 R908 1-215-878-00 METAL OXIDE 33K 5% 1W
(US,CND,MX)
0 R908 1-215-901-00 METAL OXIDE 33K 5% 2W
(TW,AUS)
0 R908 1-215-904-11 METAL OXIDE 100K 5% 2W
(AEP,CIS,UK,E12,E32,EA,MY,SP,HK,KR,AR)
0 R909 1-247-887-00 CARBON 220K 5% 1/4W
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
0 R909 1-260-127-11 CARBON 220K 5% 1/2W
(US,CND,AEP,CIS,UK,KR,MX)
0 R910 1-215-884-31 METAL OXIDE 47 5% 2W
(US,CND,MX)
0 R910 1-215-884-11 METAL OXIDE 47 5% 2W
(TW,AUS)
0 R910 1-215-909-11 METAL OXIDE 47 5% 3W
(E12,E32,EA,MY,SP,HK,AR)
0 R911 1-249-425-11 CARBON 4.7K 5% 1/4W F
(US,CND,AEP,CIS,UK,TW,KR,MX,AUS)
0 R911 1-249-426-11 CARBON 5.6K 5% 1/4W
(E12,E32,EA,MY,SP,HK,AR)
0 R912 1-249-428-11 CARBON 8.2K 5% 1/4W F
(E12,E32,EA,MY,SP,HK,AR)
0 R912 1-249-426-11 CARBON 5.6K 5% 1/4W
(US,CND,AEP,CIS,UK,TW,KR,MX,AUS)
0 R913 1-249-385-11 CARBON 2.2 5% 1/6W F
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
0 R913 1-249-399-11 CARBON 33 5% 1/4W F
(US,CND,AEP,CIS,UK,KR,MX)
R914 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R915 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R916 1-249-420-11 CARBON 1.8K 5% 1/4W F
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
R916 1-249-421-11 CARBON 2.2K 5% 1/4W F
(US,CND,AEP,CIS,UK,KR,MX)
R917 1-249-420-11 CARBON 1.8K 5% 1/4W F
(US,CND,MX)
R917 1-249-422-11 CARBON 2.7K 5% 1/4W F
(EXCEPT US,CND,MX)
R918 1-215-884-11 METAL OXIDE 47 5% 2W
(US,CND,MX)
R919 1-249-429-11 CARBON 10K 5% 1/4W
(US,CND,AEP,CIS,UK,KR,MX)
R919 1-249-433-11 CARBON 22K 5% 1/4W
(TW,AUS)
R919 1-249-436-11 CARBON 39K 5% 1/4W
(E12,E32,EA,MY,SP,HK,AR)
R920 1-249-427-11 CARBON 6.8K 5% 1/4W F
(E12,E32,EA,MY,SP,HK,AR)
R920 1-249-433-11 CARBON 22K 5% 1/4W
(US,CND,AEP,CIS,UK,TW,KR,MX,AUS)
R921 1-216-853-11 METAL CHIP 470K 5% 1/16W
(US,CND,MX)
R921 1-216-851-11 METAL CHIP 330K 5% 1/16W
(AEP,CIS,UK,KR)
R921 1-216-857-11 METAL CHIP 1M 5% 1/16W
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
R922 1-216-841-11 METAL CHIP 47K 5% 1/16W
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
R922 1-216-844-11 METAL CHIP 82K 5% 1/16W
(AEP,CIS,UK,KR)
R922 1-216-843-11 METAL CHIP 68K 5% 1/16W
(US,CND,MX)
R923 1-216-833-11 METAL CHIP 10K 5% 1/16W
R924 1-216-818-11 METAL CHIP 560 5% 1/16W
(US,CND,AEP,CIS,UK,KR,MX)
R925 1-216-812-11 METAL CHIP 180 5% 1/16W
(AEP,CIS,UK,KR)
R925 1-216-811-11 METAL CHIP 150 5% 1/16W
(US,CND,MX)
R925 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
R926 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R927 1-215-865-11 METAL OXIDE 220 5% 1W
(US,CND,MX)
R927 1-249-417-11 CARBON 1K 5% 1/4W F
(E12,E32,EA,MY,SP,HK,TW,AR,AUS)
R928 1-216-837-11 METAL CHIP 22K 5% 1/16W
(EXCEPT US,CND,MX)
R928 1-216-841-11 METAL CHIP 47K 5% 1/16W
(US,CND,MX)
R929 1-216-809-11 METAL CHIP 100 5% 1/16W
R932 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT US,CND,MX)
