Sony HDCU3500 User Manual

18
UHD-SDI connectors
Displayed only when HKCU-SDI50 is installed.
IP-OUT connectors
Displayed only when HKCU-SFP50 is installed.
Camera and unit audio status
Camera MIC Gain CH1: Camera microphone circuit 1 amp
gain status
Camera MIC Gain CH2: Camera microphone circuit 2 amp
gain status
CCU AES/EBU Out: Output format of the AES/EBU connector
CCU Analog Out: Output format of the analog output
connector
Camera and unit intercom status
Camera Engineer: Camera microphone status of the ENG
line of the camera
Camera Producer: Camera microphone status of the PROD
line of the camera
CCU MIC/PGM: Status of MIC/PGM switch on the front of the
unit
CCU Line: Intercom system connection status
Network status
Displayed only when HKCU-SFP50 is installed.
LAN1: Link status of the LAN1 connector
SPD1: Link speed of the LAN1 connector
FEC1: FEC setting for 25G of the LAN1 connector
LSM1: Connection status of the LAN1 connector with Live
System Manager
PTP1: Network genlock status of the LAN1 connector
* The above items are also shown for the LAN2 connector.
Ref: Used reference format setting and genlock status
RDS: Connection status with NMOS Registration & Discovery
System
*Multi Format3* 04/11
UHD-SDI
A 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
B 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
C 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
D 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
*Multi Format4* 05/11
UHD-SDI
E 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
F 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
G 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
H 3840x2160/59.94P/12G
OETF:HLG_BT2100 COLOR: BT2020
*Multi Format IP* 06/11
IP-OUT
1:1080/59.94P/3G-A
0ETF:HLG_BT.2100 Color: BT.2020
SOURCE:CAMERA
2:M 1080/59.94P/3G-A
0ETF:HLG_BT.2100 Color: BT.2020
SOURCE:CAMERA
3:C 1080/59.94P/3G-A
0ETF:HLG_BT.2100 Color: BT.2020
SOURCE:HD TRUNK
*Audio* 07/11
Camera
MIC Gain CH1 :60dB
CH2 :60dB
CCU
AES/EBU Out :AES/EBU
Analog Out :AES/EBU
*Intercom* 08/11
Camera
Engineer :MIC On
Producer :MIC Off
CCU
MIC/PGM :MIC Off
Line :System
*Network* 09/11
LAN 1:Link Up 2:Link Up
SPD 1:25G 2:25G
FEC 1:RS-FEC 2:RS-FEC
LSM 1:Disconnected 2:Disconnected
PTP 1:Locked 2:Locked
Ref :1080/50I
Locked
RDS :Connected

Sony HDCU3500 Specifications

General

Type	Camera Control Unit
Video Input	12G-SDI, 3G-SDI, HD-SDI
Video Output	12G-SDI, 3G-SDI, HD-SDI
Rack Mountable	Yes
Control Interface	RS-422
Power Requirements	AC 100 V to 240 V, 50/60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
