Note
When adhering the WALL MOUNT TEMPLATE on the wall, smooth it out fully.
Install the bar speaker apart from the TV by 70 mm (2 7/8 in) or more.
5-034-491-11(1)
Copyright 2022 Sony Corporation
Screws
Marks
(e) 270 mm (10 3/4 in)
(f) 10 mm to 11 mm (approx. 7/16 in)
Remove the WALL MOUNT TEMPLATE.
5
Hang the bar speaker on the screws.
Align the holes of the rear of the bar speaker with the screws, then hang the bar speaker on the two screws.
6
To Next Page
