© 2021 Sony Corporation Printed in Malaysia
4
Connect the control box, then the speakers to the AC outlet (mains)
連接控制器，然後將主動式揚聲器連接到交流電插座
ARC/
eARC
HDMI 出力 HDMI IN
12V
S-CENTER 出力
AC adaptor (supplied)
交流變壓器（附帶）
AC power cord (mains lead) (supplied)
交流電源線（附帶）
AC power cord (mains lead) (supplied)
交流電源線（附帶）
Connect the AC adaptor (supplied) to the control box, the AC power cord
(supplied) to the AC adaptor, and then the AC power cord to the AC outlet
(mains).
Connect the AC power cords (supplied) to the speakers and then to the AC
outlets.
將交流變壓器（附帶）連接到控制器，將交流電源線（附帶）連接到交流變壓
器，然後將交流電源線連接到交流電插座。
將交流電源線（附帶）連接到主動式揚聲器，然後連接到交流電插座。
5
Set up the remote control
設定遙控器
6
Turn on the control box, then the TV
開啟控制器，然後開啟電視機
Speaker connection check
Next
Speaker connection successful.
PLEASE WAIT SETUP
Power ON
電源開啟
Speaker connection check
•揚聲器連線檢查
Press the (power) button on the remote control of the speaker system to
turn on the control box.
The speaker system turns on and [SETUP] appears in the front panel display of the
control box.
Turn on the TV.
If the [Speaker connection check] screen does not appear on the TV screen, change the
TV input setting to the input that the speaker system is connected.
Check that the connection between the control box and 4 speakers is
completed on the TV screen.
The control box and speakers are connected automatically.
The sound for connection completion is output after the check marks appear on all the
speakers.
The power indicator of the speaker lights in green when connecting to the control box.
按下揚聲器系統遙控器上的（電源）按鈕，開啟控制器。
揚聲器系統開啟，控制器的前顯示面板上出現[SETUP]。
開啟電視機的電源。
如果電視機螢幕上沒有出現[揚聲器連線檢查]畫面，請將電視機輸入設定變更為已連接揚聲
器系統的輸入。
在電視機螢幕上檢查控制器與4個主動式揚聲器之間的連接是否完成。
控制器與主動式揚聲器會自動連接。
所有主動式揚聲器上出現核選標記之後，會輸出連接完成的聲音。
主動式揚聲器連接到控制器時，電源指示燈會呈綠色。
Note
• To use the speaker system, point the remote control at the front of the control box.
• Depending on the order in which you turn on the TV and the speaker system, the speaker system
may be muted and [MUTING] may appear on the front panel display of the control box. If this
happens, turn off all devices, and then turn on the TV first, then the speaker system.
• If you connect the TV center speaker mode cable (supplied) to the control box and your TV, follow the
instructions on the TV screen for the settings after Step 6.
註
•• 若要使用揚聲器系統，請將遙控器對準控制器正面。•
•• 依據您開啟電視機與揚聲器系統的順序，揚聲器系統可能會靜音，而且控制器的前顯示面板上可能會出現
[MUTING]。如果發生這種狀況，請關閉所有裝置，然後先開啟電視機，再開啟揚聲器系統。•
•• 如果將中心揚聲器模式訊號線（附帶）連接到控制器和電視機，請按照電視機螢幕上的指示操作步驟6之後
的設定。
7
Perform Initial Settings
執行初始設定
Sound Field Optimization
Later
Optimize the surround sound for your environment.
Optimization takes about a minute. A loud sound
may come from your speakers during optimization.
Do not make loud noises, walk or stand in front of
the speakers during optimization.
Start
Easy Network Setup - Start
Connect this unit to the Internet to:
- Use your mobile device to play streaming music on the unit.
- Install software updates to keep the latest functions available.
You can do this later from [Easy Setup] > [Easy Network Setup].
Next Later
Language
Select your language.
Français (France)
English
Français (Canada)
Español
Deutsch
Language
•語言
////
Sound Field Optimization
•音場最佳化
Easy Network Setup - Start
•簡易網路設定•-•開始
Press /// and to select an item by following the on-screen
instructions.
When the Sound Field Optimization is complete and you have finished listening to the
demo music, press [Next] to continue network settings.
Once [Setup is complete.] appears, select [Finish].
按下///和 ，按照螢幕上的指示選擇一個項目。
當音場最佳化完成，而且您已聽完示範音樂後，請按[下一步]繼續網路設定。
出現[設置已完成。]後，選擇[完成]。
Note
• During the Sound Field Optimization, a measurement sound is output for about 1 minute.
• The speaker system does not output sound until the connection between the control box and 4
speakers is completed.
註
•• 在音場最佳化期間，將輸出測量聲音約1分鐘。
•• 在控制器與4個主動式揚聲器之間的連接完成之前，揚聲器系統不會輸出聲音。
8
Listen to sound
聆聽聲音
TV input switch
電視機輸入開關
TV
HDMI
Listen to TV Audio
Select the desired input to the TV using the TV remote control.
The screen switches to the selected input screen and TV audio is output from the
speaker system.
If [TV] does not appear in the front panel display of the control box, press TV on the
remote control of the speaker system to select the TV input. [TV] appears in the front
panel display of the control box.
Listen to audio of another device connected to the HDMI IN jack on
the control box
Turn on the connected device. Then use the TV’s remote control to switch the
TV’s input to HDMI input to which the speaker system is connected.
Press HDMI on the remote control of the speaker system to switch to HDMI
input.
[HDMI] appears in the front panel display of the control box and the audio of the
connected device is output from the speaker system.
聆聽電視機的聲音
使用電視機遙控器選擇所要的電視機輸入。
畫面切換為所選輸入畫面，而且揚聲器系統輸出電視機的聲音。
如果控制器的前顯示面板上沒有出現[TV]，請按下揚聲器系統遙控器上的TV以選擇電視機輸
入。控制器的前顯示面板上出現[TV]。
聆聽連接到控制器HDMI IN插孔的其他裝置之音訊
開啟連接的裝置之電源。然後使用電視機遙控器將電視機輸入切換為揚聲器系統
連接的HDMI輸入。
按下揚聲器系統遙控器的HDMI，以切換到HDMI輸入。
控制器的前顯示面板上出現[HDMI]，連接裝置的音訊會從揚聲器系統輸出。
How to use the speaker system / Troubleshooting
如何使用揚聲器系統/故障排除
Home Theatre System
Operating Instructions (booklet)
Describes basic usage such as installation/connection
and playback of connected devices.
Help Guide (Web instruction manual)
Describes all the usage such as the network function
and the detailed setting method, including the contents
of the Operating Instructions.
For troubleshooting when the speaker system does not
operate correctly, see “Troubleshooting” in the Operating
Instructions or Help Guide.
使用說明書（小冊子）
描述基本使用，例如安裝/連接和播放連接裝置。
說明指南（網頁版使用說明書）
描述所有使用，例如網路功能和詳細設定方法，包括使用說
明書的內容。
有關揚聲器系統無法正常操作時的故障排除，請參閱使用說
明書或說明指南中的“故障排除”。
https://rd1.sony.net/help/ht/a9/h_zz/
