The illustrations below are examples of how to install the speaker.
• When you select a place for the receiver or the subwoofer, do not block the heat ventilation on the rear panel of the
receiver or the subwoofer.
Installing the speaker to the
TV
You can install the speaker on the following TV
models (not supplied) by using the
WS-CT550B40/46 speaker attachment bracket
(not supplied):
• Installing the speaker on the TV stand
• Hanging the speaker and TV on a wall
Installing the speaker and the
TV separately
If you cannot install the speaker to the TV, you
can install the speaker as shown below.
• Installing the speaker in a rack
• To prevent speaker vibration or movement while
listening, attach the supplied speaker foot pads to the
bottom four corners of the speaker.
• Installing the speaker on a wall (page 13)
Positioning the system
Note
KDL-46HX92s, KDL-46HX82s,
KDL-40/46NX72s, KDL-40/46HX72s,
KDL-40/46EX72s
* In the actual model names, the “s” indicates
numbers and/or characters specific to each
model.
As of May 2011.
Note
To Next Page
