46
GB
1280 × 720p 29.97/30 Hz
Frame packing
Side-by-Side (Half)
Over-Under
(Top-and-Bottom)
Deep Colour: 30bit/36bit
Audio inputs BD/DVD, GAME, SAT/
CATV: See “Formats
supported by this system”
(page 45).
Tuner section
System PLL quartz-locked digital
synthesizer
FM tuner section
Tuning range 87.5 - 108.0 MHz
(50 kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
General
Power requirements 220 V -240 V AC,
50/60 Hz
Power consumption
On: 50 W
Standby mode: 0.3W or less (Control for HDMI
is off.)
Dimensions (approx.) 270 mm × 60 mm ×
286 mm (w/h/d)
Mass (approx.) 1.9 kg
Speaker (SS-CT550W)
Front speaker unit
Speaker system Bass Reflex
Speaker unit 50 mm, cone type × 2
Rated impedance 4 ohms
Dimensions (approx.) 948.2 mm × 75 mm ×
40 mm (w/h/d)
Mass (approx.) 2.3 kg
Speaker cords 3 m
Subwoofer (SA-WCT550W)
Amplifier section
POWER OUTPUT (reference)
134 W (per channel at
4 ohms, 100 Hz)
Speaker system Subwoofer, Bass reflex
Speaker unit 160 mm cone type
Rated impedance 4 ohms
Power requirements 220 V - 240 V AC,
50/60 Hz
Power consumption
On: 30 W
Standby mode: 0.5 W or less
Dimensions (approx.) 270 mm × 389 mm ×
280.5 mm (w/h/d)
Mass (approx.) 8.8 kg
Wireless transceiver (EZW-RT50)
Communication System Wireless sound
Specification version 1.0
Frequency band 5.725 GHz - 5.875 GHz
Power requirements DC 3.3 V, 300 mA
Modulation method DSSS
Dimensions (approx.) 30 mm × 9 mm × 60 mm
(w/h/d)
Mass (approx.) 10 g
Design and specifications are subject to change without
notice.
• Standby power consumption 0.5 W or less.
• Over 85 % power efficiency of amplifier block is
achieved with the full digital amplifier, S-Master.
