Sony HT-DDW670 - FM tuner section; AM tuner section; General

Additional Information
masterpage:Right
lename[E:\SEM_Janet\Revision_DDW670\J904000_2342216121DDW670_GB\2342216121\G
B
09ADD_HT-DDW670-U.fm]
41
GB
model name1[HT-DDW670]
[2-342-216-12(1)]
Models of area code AU
(6 ohms 120 Hz – 20 kHz, THD 0.09%)
FRONT
2)
: 40 W/ch
CENTER
2)
: 40 W
SURR
2)
: 40 W/ch
(6 ohms 100 Hz, THD 0.09%)
SUB WOOFER
2)
: 40 W
(6 ohms 1 kHz, THD 0.7%)
FRONT
2)
: 50 W/ch
CENTER
2)
: 50 W
SURR
2)
: 50 W/ch
(6 ohms 100 Hz, THD 0.7%)
SUB WOOFER
2)
: 50 W
(6 ohms 1 kHz, THD 10%)
FRONT
2)
: 85 W/ch
CENTER
2)
: 85 W
SURR
2)
: 85 W/ch
(6 ohms 100 Hz, THD 10%)
SUB WOOFER
2)
: 85 W
1) Measured under the following conditions:
2) Depending on the sound field settings and the
source, there may be no sound output.
Inputs (Analog)
Inputs (Digital)
Output (Analog)
Reproduction frequency range:
28 – 20,000 Hz
Tone
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Models of area code U, CA
With 10-kHz tuning scale: 530 – 1,710 kHz
3)
With 9-kHz tuning scale: 531 – 1,710 kHz
3)
Models of area code CEL, CEK, AU, SP
With 9-kHz tuning scale: 531 – 1,602 kHz
Model of area code E51
With 10-kHz tuning scale: 530 – 1,610 kHz
3)
With 9-kHz tuning scale: 531 – 1,602 kHz
3)
Models of area code MX
With 10-kHz tuning scale: 530 – 1,610 kHz
Antenna Loop antenna
Intermediate frequency 450 kHz
3) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off the
receiver. While holding down PRESET TUNING +
or TUNING +, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the procedure.
General
Power requirements
Power consumption
Area code Power requirements
U, CA 120 V AC, 60 Hz
CEL, CEK, SP 230 V AC, 50 Hz
AU, E51 240 V AC, 50 Hz
MX 127 V AC, 60 Hz
SA-CD/CD, DVD,
VIDEO 1, 2
Sensitivity: 800 mV
Impedance: 50 k ohms
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
SA-CD/CD (Optical) Sensitivity: –
Impedance: –
SUB WOOFER Voltage: 2 V
Impedance: 1 k ohm
Gain levels ±6 dB, 1 dB step
Area code Power requirements
U, CA 120 V AC, 60 Hz
CEL, CEK 230 V AC, 50/60 Hz
AU 240 V AC, 50 Hz
E51 120/220/240 V AC,
50/60 Hz
SP 220-230 V AC, 50/60 Hz
MX 127 V AC, 60 Hz
Area code Power consumption
U, SP, E51, AU, CEL,
CEK, MX
160 W
CA 220 VA
continued
