About the indicators on the display
SW
LFE
LCR
SL S SR
;
D
;
PLII
;
PL OPT DTS MEMORY RDS ST
MONOD.RANGECOAX
1 2 3 4 5 6 87
qs qa 9q;
Name Function
A SW Lights up when audio signal is
output from the SUB WOOFER
jack.
B LFE Lights up when the disc being
played back contains an LFE
(Low Frequency Effect)
channel and the LFE channel
signal is actually being
reproduced.
C ; D Lights up when the receiver is
decoding Dolby Digital signals.
D ; PL/
; PLII
“; PL” lights up when the
receiver applies Pro Logic
processing to 2 channel signals
in order to output the center and
surround channel signals.
“; PLII” lights up when the
Pro Logic II Movie/Music
decoder is activated.
E OPT Lights up when VIDEO 2 input
is selected. However,
“UNLOCK” appears on the
display if no digital signal is
input through the OPTICAL
jack.
Name Function
F DTS Lights up when the receiver is
decoding DTS signals.
G MEMORY Lights up when a memory
function, such as Name Input,
Preset Memory (page 48), etc.,
is activated.
H Tuner
Indicators
Lights up when using the
receiver to tune in radio stations
(page 46), etc.
Note
“RDS” appears for models of
area code CEL, CEK only.
I Preset
station
indicators
Lights up when using the
receiver to tune in radio stations
you have preset. For details on
presetting radio stations, see
page 48.
J D.RANGE Lights up when dynamic range
compression is activated (page
34).
K COAX Lights up when DVD input is
selected. However,
“UNLOCK” appears on the
display if no digital signal is
input through the COAXIAL
jack.
continued
