Overview
TIME CODE [> Time
Code]: Set
timecode.
9P TC PHASE [>>
9P TC Phs]:
Select
reference for 9-
pin status
sense
timecode.
*SD [>>> SD]: Align with SD phase.
HD [>>> HD]: Align with HD phase.
EMBED VITC [>>
Embd VITC]:
Select
timecode
embedded in
HD-SDI output
for up-
conversion.
*LTC [>>> LTC]: Use LTC as VITC to be
embedded in the HD-SDI output.
VITC [>>> VITC]: Use VITC as VITC to be
embedded in the HD-SDI output.
AUTO ASPECT [> Auto Aspct]: Select
whether to handle the aspect ratio
discriminator signal included in the SD
signal.
Note
When this is set to ON but no aspect ratio
discriminator signal is detected, follows the
MANUAL ASPECT setting.
*ON [>> ON]: The aspect ratio flags in the
SD signal, and automatically set
display mode for up-conversion.
OFF [>> OFF]: The MANUAL ASPECT
setting. (Ignore aspect ratio flags in
the SD signal.)
MANUAL ASPECT [>Manual Asp]:
Select the aspect ratio conversion
method for up-conversion.
For details of the conversion from 4:3 to 16:9,
see page 30.
*EDGE-CROP [>> Edge Crop]: Use
edge crop mode for input SD
signals.
a)
LETTER BOX [>> L-Box]: Use letterbox
mode for input SD signals.
b)
SQUEEZE [>> Squeeze]: Use squeeze
mode for input SD signals.
c)
UP/CROSS CONVERTER [Up/Cross]:
Settings relating to the up-conversion/
cross-conversion function
Description of settings
